15 ENGLISH
NOTICE: Do not pull the switch trigger forcibly
without pressing the lock-off button.Theswitch
maybreak.
►Fig.3: 1. Switch trigger 2.Lock-offbutton
Tostartthetool,depressthelock-offbuttonandpullthe
switchtrigger.Releasetheswitchtriggertostop.The
lock-offbuttoncanbepressedfromeithertherightor
leftside.
Indicator lamp
Theindicatorlampblinksorlightsupwhentheremain-
ingbatterycapacityisloworempty.Theindicatorlamp
alsolightsupwhenthetoolbecomesoverloaded.
►Fig.4: 1. Indicator lamp
Lamp status and action to be taken
Indicator lamp Status Actiontobetaken
Thelampblinks
red.
Theremaining
batterycapacity
is low.
Chargethebattery.
Thelamplightsup
red. *
Thetoolhas
stoppedbecause
the remaining
batterycapacityis
empty.
Chargethebattery.
Thetoolhas
stopped due to
overload.
Turnoffthetool.
*Thetimeatwhichtheindicatorlamplightsupvariesdepending
onthetemperaturearoundtheworkareaandthebatterycar-
tridge conditions.
Adjusting the shearing height (for
grass shear)
CAUTION: When changing the shearing
height, be sure to attach the blade cover and be
careful not to trap ngers between the tool and
grass receiver.
Theshearingheightcanbesettothreelevels(15mm,
20mm,and25mm)bychangingthexedpositionof
thegrassreceiver.Theshearingheightwithoutthe
grassreceiverisabout10mm.
1. Slidethegrassreceivertowardthefrontofthe
tool.
►Fig.5: 1. Grass receiver
2. Changethexedpositionofthegrassreceiverby
movingitinthedirectionofthearrow.
►Fig.6
NOTE:Theshearingheightvalueisaguideline.The
actual shearing height may vary depending on the
conditionofthelawnortheground.
NOTE:Tryatestshearinginalessconspicuous
place to get your desired height.
ASSEMBLY
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before carrying out any work on the tool.
CAUTION: When replacing the shear blades,
always wear gloves and attach the blade cover so
that your hands and face do not directly contact
the blades.
NOTICE: When replacing the shear blades, do
not wipe off grease from the gear and crank.
Installing or removing the blade
cover
CAUTION: Be careful not to touch the blades
when installing or removing the blade cover.
Toremovethebladecover,pullitslightly,andthenslide
itsideways.Toinstallthebladecover,performthesteps
in reverse.
►Fig.7
Installing or removing the grass
receiver
CAUTION: When installing or removing the
grass receiver, be sure to attach the blade cover
and be careful not to trap your ngers between
the tool and grass receiver.
Removing the grass receiver
1. Release the protrusions on the grass receiver
fromthegroovesonthetoolwhileslidingthegrass
receivertowardthefrontofthetool.
►Fig.8: 1. Grass receiver
2. Releasethehingeofthegrassreceiverfromthe
tool.
Installing the grass receiver
1. Hookthehingeofthegrassreceiveronthegroove
ofthetool.
►Fig.9: 1. Hinge 2. Grass receiver
2. Aligntheprotrusionsonthegrassreceiverwith
thegroovesonthetoolbyslidingthegrassreceiver
towardthefrontofthetoolandmovingitinthedirection
ofthearrow.
►Fig.10
NOTICE: Do not attach the hinge of the grass
receiver to the tool forcibly after aligning the pro-
trusions on the grass receiver with the grooves
on the tool.
