ENGLISH

www.euroteplo.ru

SYMBOLS USED:

Please view the symbols and insignia used in this manual.

Prohibited. Used to specify prohibition of

certain actions. A failure to comply with this

recommendation may lead to both a breakdown

of the product itself and a possible harm to the

health of people around.

Attention. Used to note especially important

assembly rules and highlights.

Note. This symbol marks an additional useful

information that is not necessarily directly related to

the purchased product.

HEAT LINE Manufacturing Company LLC

Any reproduction, transfer, distribution, translation or any

other processing, including electronic and digital, of this

manual or any of its parts without prior written consent of

HEAT LINE Manufacturing Company LLC are prohibited.

TRADEMARK

logo is a registered trademark of HEAT

LINE Manufacturing Company LLC.

2. DESIGNATION

The Heatline-2 underfloor heating system is intended

for both basic and additional space heating with the

ceiling height not more than 4 meters. The heat source is

a heating unit laid in cement and sand screed.

If you are going to heat a balcony, a recessed

balcony, a winter garden, a room with a ceiling of

4 meters height and higher or to use the electric

underfloor heating as the main source of heating

contact HEAT LINE Manufacturing Company LLC at

8-800-333-58-25 (free for the Russian Federation).

1. GENERAL

Dear customer!

Thank you for purchasing a Heatline-2 twin-cored

underfloor heating set manufactured by HEAT LINE

Manufacturing Company LLC, Russia.

Employment of state-of-the-art technologies and

highest quality materials when manufacturing this

product have been the reasons for popularity and

credibility of Heatline® trademark. The twin-cored

Heatline-2 underfloor heating is manufactured

in strict compliance with international standards

guaranteeing reliability and safety of operation.

HEAT LINE Manufacturing Company LLC has an ISO

9001-2011 (ISO 9001:2008) ГОСТ Р ИСО 14001-

2007 (ISO14001:2004) ГОСТ 12.0.230-2007 (04SAS

1800:2007) international quality certificate.

• Before installing the set read this instruction

manual describing the sequence of operations

when assembling Heatline-2 twin-cored

underfloor heating.

• Installation of the underfloor heating and

thermostat must be carried out ONLY by a

trained professional (electrician), who has relevant

professional experience and the proper tools for

installation operations!

• The manufacturer and the seller DO not bear

any responsibility for ANY breakdowns, failures,

injuries, casualties arisen due to unskilled

installation of this equipment!

• Read the inserted label details and compare the

type of the underfloor heating mentioned on the

inserted label card with the type on the box. Make

sure that the Set you have chosen fits your rooms.

It is important to take careful measurements. Keep

the label and related paperwork untill the end of

the warranty period. Without the label the warranty

is INVALID!

3. CONTENTS

The Heatline-2 underfloor heating includes the following

(Figure А1–A3):

1. 20P2E-MMM-PPPP heating unit, where MMM is a

unit length and PPPP is a unit nominal rating power

in watts.

2. Assembly tape.

3. Flexible corrugated tube to assemble the

temperature gage.

4. Underfloor electrical heating electrical assembly

manual.

5. Insert label card.

6. Packing.

4. INSTALLATION CONDITIONS

Installation is permitted at temperatures in the room not

less than +10

С and relative humidity not more than

80%.

5. TOOLS REQUIRED FOR INSTALLATION:

5.1. Perforator/impact drill.

5.2. Wall chaser.

5.3. Flat-nose pliers.

5.4. Cutters.

5.5. Crimping pliers.

5.6. Set of screw-drivers.

5.7. Wire stripper.

5.8. Ohmmeter.

5.9. Megohmmeter.

5.10. Electrician’s screw-driver (voltage detector).

5.11. Measuring tape.

5.12. Electric knife.

5.13. Lead pencil.

LIST OF CONTENTS

1. General .............................................................................. 20

2. Designation ...................................................................... 21

3. Contents ........................................................................... 21

4. Installation conditions .................................................... 21

5. Tools required for installation ....................................... 21

6. Heatline-2 twin-cored underfloor heating ................... 22

7. Assembly tape ................................................................. 22

8. Thermostat ....................................................................... 22

9. Preparation for installation............................................. 22

10. Wiring system ................................................................ 22

11. Heatline-2 underfloor heating installation ................. 23

11.1. Connecting Heatline-2 underfloor

heating to Thermostat ........................................................ 24

12. Heatline-2 underfloor heating

actuation and operation ..................................................... 24

13. Safety .............................................................................. 24

14. Heatline-2 twin-cored heating unit Parameters ....... 25

15. Warranty Certificate (to be filled in by the trading and

installation companies) ....................................................... 25

16. Warranty liabilities ........................................................ 26

17. Acceptance Certificate ................................................. 27

18. Manufacturer ................................................................. 27
