ENGLISH en

Use only as

accessories.

Use only sharp, undamaged saw blades. Do

not use accessories that are cracked or that

have changed their shape. Use an accessory that is

suitable for the material being sawn.

See fig. 1, 3 and 4, page 2.

1. Swivel the clamping lever (2) forwards by 180

2. Turn the spring pin (20) slightly in anti-clockwise

direction and remove.

3. Put the accessory in the desired position on the

tool holder (18) or remove from the tool holder

(18) . Ensure that it engages in the cams of the

tool holder (18) .

4. Insert the spring pin (20) and turn by 90

clockwise direction.

5. Caution! The clamping lever (2) may spring

back and can crush your fingers. Handle

carefully. Wear protective gloves.

Close the clamping lever (2) until the stop and

engage. (The release lever has to be in contact

with the housing).

6. Check the accessories for firm hold.

7.3 Installation of sanding disc

Simple attachment and removal thanks to the hook

and loop fastening. Simply press on the sanding

disc so that the holes of sanding disc (21) match.

7.4 Attaching the depth guide

See fig. 2, page 2

Undo the screw (14) on the dust extraction (11) .

Set depth guide (13) to the desired depth. Tighten

the screw (14) again.

7.5 Switching On and Off

Switch on first, then guide the accessory

towards the workpiece.

Avoid switching on the machine accidentally:

always switch it off when the battery pack is

removed from the machine.

Avoid the machine swirling up or taking in dust

and chips. After switching off the machine,

only place it down when the motor has come to a

standstill.

Switching on: Push the slide switch (3) forward

(continuous operation).

Switching off: Push the slide switch (3)

backwards.

7.6 Setting the oscillating frequency

See fig. 1, page 2

Set the oscillating frequency on the adjustment

wheel (5). This can also be done during operation.

The best way to determine the ideal setting is

through a practical trial.

For sanding plate Ø 150 maximum speed 8.

7.7 Working Directions

Sandpaper grinding: The ideal setting is best

determined by a practical test. Apply moderate

pressure on the machine and move it to and fro

across the surface.

Cutting, sawing: Set high oscillation frequency.

Press down the machine evenly. Avoid jamming!

For plunge cuts: A slight tilting movement speeds

up the work progress.

Scraping: Set medium to high oscillation

frequency.

Hold the accessory at a flat angle to the workpiece.

See fig. 4, page 2:

To turn the accessory (19), loosen the clamping

lever (2),turn the accessory in the tool holder to the

desired position and close the clamping lever again.

Clean the machine regularly. This includes

vacuum cleaning the ventilation louvres on the

motor.

9.1 The machine's multifunctional

monitoring system

If the machine switches off automatically, the

machine electronics have activated automatic

protection mode.

In spite of this protective function, overloading

is still possible with certain applications and

can result in damage to the machine.

Causes and remedies:

1. Battery pack almost flat (the electronics

prevent the battery pack from discharging totally

and avoid irreparable damage).

If one LED (7) is flashing, the battery pack is

almost flat. If necessary, press the button (6) and

check the LEDs (7) to see the charge level. If the

battery pack is almost flat, it must be recharged!

2. Long continuous overloading of the machine will

activate the temperature cut-out.

Leave the machine or battery pack to cool.

Note:

If the battery pack feels very warm, the

pack will cool more quickly in an "AIR COOLED"

charger.

Note:

The machine will cool more quickly if you

operate it at idling speed.

3. The machine does not run and the LED light

(1) flashes. The restart protection is active. The

machine will not start if the battery pack is

inserted while the machine is on. Switch the

machine off and on again.

Use only original Metabo or CAS (Cordless Alliance

System) battery packs and accessories.

8. Cleaning, Maintenance

9. Troubleshooting

10. Accessories
