SELECTING THE RPM

The number of revolutions can be adjusted by using the speed

control (3) from MAX to OFF. The choice of speed depends on the

characteristics of the abrasive paper disc and the material to be

worked.

REPLACING THE ABRASIVE PAPER DISCS

- Used discs can be removed by simply tearing them off;

- new velcro discs are mounted by simply pressing them into the

backing pad, making sure that the holes cut in the disc coincide

with those in the backing pad.

USABLE DISCS

Ø mm 150 velcro backed abrasive paper discs with dust

extraction holes.

MAINTENANCE

All maintenance operations are carried out with the tool

disconnected from the compressed air supply.

At the end of each work session, or when required, remove any

dust from the body of the tool using a jet of compressed air.

Lubricate the machine regularly (every 50 hours of operation)

by inserting 2/3 drops of specific oil (synthetic oil without

silicone, ISO 32) into the compressed air connection, keeping

the device in a vertical position, with the connection facing

upwards. After this operation, connect the machine to the

power supply and set it in motion for a few seconds.Lubricate

the machine as described above before storing it for long

periods of inactivity.All damages deriving from incorrect or

inadequate lubrication are excluded from the warranty.

No other maintenance operations must be undertaken by the user.

Maintenance and cleaning of the inner parts, must be carried out

only by an authorized customer-service workshop.

NOISE / MEAN ACCELERATION VALUE

The noise level produced and themean quadratic acceleration

value are measured according to regulation

UNI EN ISO 15744 - EN ISO 28927.

Displayed emission values are comparative and are to be

employed for a provisional assessment of the operator’s risk

exposure during the work period. Appropriate evaluation of work

period must also include tool’s idle and stop periods. These

emission values represent the tool’s main applications. If the tool

is used for other applications, with other accessories, or if it does

not undergo regular maintenance, emission values can

significantly increase during operations.

Danger! The indicate measurements refer to new power tools. Daily usa

causes the noise and vibration values to change.

Sound pressure level Vibration level

Sound power level 3 axis 1 axis*

Uncertainty

dB(A) m/s

m/s

RH253 73 84 3 2,80 0,20 <2,5 0,2

RH256 75 86 3 3,00 0,30 2,6 0,3

RH259 76 87 3 3,20 0,35 2,8 0,35

RH253A 74 85 3 2,80 0,20 <2,5 0,2

RH256A 76 87 3 3,00 0,30 2,6 0,3

RH259A 77 88 3 3,20 0,35 2,8 0,35

* According to the EN ISO 8662.
