PARTS OF THE TOOL

1 - Identification plate

2 - Compressed air on/off lever

3 - Speed control

4 - Tool body

5 - Compressed air connection with 1/4” thread

6 - 29 mm. int. Ø suction pipe connection (A SERIES)

7 - Silencer

8 - Suction cowling

9 - Velcroed abrasive disc backing pad

10 - Back-up pad screw

STARTING UP

Before starting-up the tool, ensure that:

- the packaging is complete and does not show signs of having

been damaged during storage or transport;

- the tool is complete; check that the number and type of components

comply with that reported in this instruction booklet;

- the available compressed air production and distribution plant is

capable of satisfying the requirements reported on the tool’s

identification plate reproduced and explained on page 11.

ASSEMBLING THE TOOL

Assemble the compressed air connection (not supplied) by

screwing it into its seating (5).

COMPRESSED AIR CONNECTION (NOT SUPPLIED)

The tool is supplied without the compressed air connection; the

user can use either a quick release coupling or hose type

connection according to his needs, purke they have an hole of air

passing mm. 8. In the latter case the air line must be fixed to the

nozzle by a hose clip.

In the latter case the air line must be fixed to the nozzle by a hose

clip.

REMOVING AND MOUNTING THE BACKING PAD

- Use the spanner to unscrew the back-up pad bolt (10);

- reverse the procedure when fitting the dsc pad.

FITTING ABRASIVE PAPER DISCS

Press the abrasive disc into the pad ensuring that the holes in the

abrasive paper coincide with extraction holes in the disc pad.

BEFORE STARTING THE TOOL

Ensure that:

- the speed control (3) is in MAX position;

- the compressed air feed line and connection are in perfect

working order;

- the start lever is working properly. This must be done with the air

supply switched off;

- all the components of the tool are mounted correctly and do not

show any signs of damage;

- the tool must be connected to a suitable and efficient aspiration

device.

STARTING AND STOPPING

- Starting:

push the control lever (2) forward towards the body of

the tool and keep it pressed.

- Stopping:

release the control lever.

TEST RUN

Start the tool and check that there are no unusual vibration, no

dismatching of the abrasive paper disc.

Otherwise switch-off the tool immediately and eliminate the

cause.
