13
English
Symbol Meaning
Attention. Important.
Useful information.
Do not dispose of the power
tool in a domestic waste
container.
DWT
power tool designation
This power tool is designed for spraying and applying
liquid materials on a treated surface. It allows the user
to apply paints, varnishes, primers, preservatives,
protective and disinfectant materials, as well as to
spray water for wetting surfaces.
1
Power tool
components
Nozzle
2 Air cap
3 Coupling nut
4 Button
5 Reservoir
6 Spray volume regulator
7 Air hose
8 Cover
9 On / off switch
10 Spray gun holder
11 Base unit
12 Measuring funnel *
13 Cleaning rod *
14 Carrying belt *
15 Purge nozzle *
16 Ventilation slots
17 Flexible extension hose *
18 Tube
19 Nut
20 Lock nut
21 Discharge opening
22 Tip for connection to the base unit
23 Tip for connection of accessories
24 Filter
25 Suction hole
26 Drain hole
27 Air lter *
* Optional extra
Not all of the accessories illustrated or described
are included as standard delivery.
Installation and regulation
of power tool elements
Before carrying out any works on the power tool it
must be disconnected from the mains.
Do not draw up the fastening elements
too tight to avoid damaging the thread.
Mounting / dismounting / setting-up of
some elements is the same for all power
tool models, in this case specic models
are not indicated in the illustration.
Reservoir connection / disconnection (see g. 1-2)
Connect / disconnect reservoir 5 as shown on
gures 1-2.
[ESP05-200 T]
Prior to connecting reservoir 5, turn tube 18 (see
g. 2.2) into the position allowing maximum use up of
the material. It depends on where the spray gun will be
tilted during operation (see g. 2.3-2.4).
• Loosen the lock nut 20 and unscrew the nut 19.
• Turn the tube 18 to the required position.
• Screw the nut 19 and secure it by tightening the lock
nut 20.
Flexible extension hose connection / disconnection
(see g. 3)
[ESP01-250]
• Flexible extension hose 17 allows spraying material
onto horizontal surfaces as well as in hard-to-reach
places (for example, when painting heating radiators).
• Unscrew nozzle 1 (see g. 3).
• Screw exible extension hose 17 on, then bend it
into the required position.
• In order to disconnect, perform these steps in
reverse order.
Air hose connection / disconnection (see g. 4)
[ESP05-200 T]
• Connect the air hose 7 to the base unit 11. Insert the
tip 22 into the opening 21 after aligning the protrusions
on the tip 22 with the grooves in the hole 21. Rotate the
tip 22 as shown on gure 4.1.
• Connect the air hose 7 to the spray gun or the
purge nozzle 15. Place the tip 23 on the shank of the
accessory by pre-aligning the grooves in the tip 23 with
the protrusions on the accessory. Rotate the tip 23 as
shown on gure 4.2.
• In order to disconnect, perform these steps in
reverse order.
Initial operating
of the power tool
Always use the correct supply voltage: the power
supply voltage must match the information quoted on
the power tool identication plate.
Switching the power
tool on / off
[ESP01-250]
Switching on:
Press and hold button 4.
