English

Switching off:

Release button 4.

[ESP05-200 T]

Switching on:

Press and release on / off switch 9. In order to start

spraying material, press and hold button 4 on the

spray gun.

Switching off:

Release button 4, then press and release on / off

switch 9.

Design features

of the power tool

Sprayed material volume regulation (see g. 5)

• Using regulator 6, you can adjust the volume of

the spayed material in order to get the desired work

result.

• To decrease volume of the sprayed material, rotate

regulator 6 as shown in gure 5 (while spraying

material). Note that the excessive decrease of the

sprayed material volume leads to poorer results of

treatment (insufcient impregnation, too thin a paint

layer, etc.).

• To increase volume of the sprayed material, rotate

regulator 6 as shown in gure 5 (while spraying

material). Note that an excessive increase of the

sprayed material volume results in drips on the

treated surface and overconsumption of the sprayed

material.

Sprayed stream shape regulation (see g. 6)

[ESP05-200 T]

You can adjust the shape of the sprayed stream by

rotating air cap 2 depending on the direction of the

spray gun's movement (see g. 6.2-6.4).

• Loosen coupling nut 3 (see g. 6.1).

• Turn air cap 2 to the desired position (see g. 6.2-6.4).

• Tighten coupling nut 3.

Spray gun holder (see g. 7)

[ESP05-200 T]

The holder 10 is designed to secure the spray gun

during the movement of the power tool or during the

breaks in the work process.

Install the holder 10 as shown on gure 7.1 (the

xtures on the lugs must click shut). You can install

the holder 10 from different sides of the base unit 11.

To remove the holder 10, slightly pull the lugs and

remove the holder as shown on gure 7.2.

Carrying belt (see g. 7)

[ESP05-200 T]

To facilitate the transportation, as well as to provide

greater portability during the work, use the carrying

belt 14. Connect the belt 14 to the base unit 11 (see

g. 7.3). If necessary, adjust the length of the belt 14 so

that make carrying the power tool easier.

Recommendations

on the power tool operation

Measurement of sprayed material viscosity (see

g. 8)

The viscosity of the sprayed material should not

exceed the maximum allowable value (see technical

data table). Thicker materials should be diluted.

Please note! Always use an appropriate solvent,

otherwise the lumps will form that will result in

clogging the power tool.

Measure the viscosity using measuring funnel 12. The

temperature of the compound should be 20-22°С.

• Stir the compound thoroughly, immerse measuring

funnel 12 into it, and wait until it lls (see g. 8).

• Lift measuring funnel 12 up and let the liquid ow

out. Measure the time of liquid ow out (DIN-s) of

measuring funnel 12 using a stop-watch (from the

start of the owing-out to jet separation). Approximate

recommended viscosity values for different materials

are given below:

• impregnating agents, varnishes, synthetic resins -

undiluted, 30 DIN-s max.;

• synthetic paints, transparent varnishes - 15-35

DIN-s;

• acrylic paint - 20-35 DIN-s;

• preservatives, pesticides, oils for wood -

undiluted, 35 DIN-s max.;

• disinfectant and cleaning agents, polishes - 35

DIN-s;

• car paint - 18-22 DIN-s.

• After you are done with the measurements,

thoroughly clean measuring funnel 12 (using an

appropriate solvent).

Surface preparation

• The treated surface must be cleaned, dried, and

degreased.

• Glossy surfaces should be roughed (with

sandpaper), dust removed, and the surface should be

degreased.

• The surrounding surfaces that need protection

from precipitation of the "mist" of the sprayed material

should be covered with thick materials (paper, lm,

etc.) and lined with adhesive tape, when necessary.

Work sequence (see g. 9)

• Prepare the sprayed material and surface as

described above.

• Detach reservoir 5, ll it with the sprayed material,

and connect it to the spray gun.

• For model ESP05-200 T, adjust the stream shape.

• Switch on the power tool, adjust the volume of the

sprayed material as described above. The "mist" of

spray deection should be homogeneous and ne.

• Do a trial treatment on an unnecessary piece

of the same material in order to make sure that the

adjustments are correct.

• Spray material from a distance of 5-30 cm from the

surface (see g. 9.1).

• For model ESP01-250 - use exible extension

hose 17 when painting horizontal or sloping

surfaces.

• For model ESP05-200 T - slightly tilt the spray

gun when painting horizontal or sloping surfaces.
