SETUP & OPERATION

- CAUTION: NEVER SWITCH ON THE WATER HEATER WITHOUT WATER: Models with an electric heating

element will be certainly damaged.

- Fill the tank completely. Before powering up, open the hot water taps, drain the pipes in order

to empty the air.

- Check the tightness of the tubes and of the  ange seal under the plastic cover. In case of leaking

tighten moderately. Check the operating of the hydraulic components and of the safety valve.

- Turn the power on. After 45 to 60 minutes, depending of the capacity of the device, the water should

drip from the drain. This is normal and due to the expansion of water. Check connection leaks

and seal. During heating and according to the water quality, hot water tanks can make a bubbling

noise. This noise is normal and does not indicate any defect of the unit.

1. FLAT RANGE

1/ SETTING KNOB (Ref A and D): Manual selection of temperature setpoint. Position of ref. D is the

maximum position of temperature setting.

2/ FROST FREE Mode

(Ref. B): Automatic regulation at frost-free temperature (7°C), in order to reduce

the electric consumption during the periods of absence of the user.

3/ SHOWER READY (Ref. C): Monitoring indicator of hot water available. When the shower symbol

is turned on, volume of hot water is equal or higher than 1 shower need.

2. SQUARE RANGE

1/ SETTING KNOB (Ref A and D): Manual selection of temperature setpoint. Position of ref. C is the

maximum position of temperature setting.

2/ FROST FREE Mode

(Ref. B): Automatic regulation at frost-free temperature (7°C), in order to reduce

the electric consumption during the periods of absence of the user.

3/ HEATING LIGHT INDICATOR

(Ref. D):. When the heating element symbol is turned on, the water is

being heated.
