3. If the following conditions are met, also take this action:

Conditions: With O-ring and locking pin.

▶ Remove the O-ring from the groove in the socket. Insert the locking pin into the holes in the socket

and the square drive spindle. Then re-insert the O-ring in the groove in the socket.

4. If the following conditions are met, also take this action:

Conditions: With locking ring.

▶ Fit the locking ring into the socket.

5.5 Removing the socket 3

1. Set the forward/reverse switch to the middle position or remove the battery from the power tool.

2. Remove the locking ring or the O-ring complete with locking pin from the socket.

3. Remove the socket from the square drive spindle of the tool.

5.6 Fitting the belt hook (optional) 4

WARNING

Risk of injury! Hazard presented by a falling power tool.

▶ A falling power tool may present a risk of injury to yourself and others. Check that the belt hook is fitted

securely before beginning work.

The belt hook allows the power tool to be attached to a belt worn by the operator. The belt hook can

be fitted to allow attachment on the left or right side of the body.

1. Remove the battery. → page 7

2. Insert the belt hook into the opening provided at the base of the product.

3. Secure the belt hook with the two screws.

5.7 Hilti Installing the retaining strap (optional) 5

ATTENTION

Damage to the product and / or the lanyard. Incorrect handling can result in damage to the product and/or

lanyard.

▶ Do not use a metal chain as a lanyard. Do not use lanyards longer than 2,0 m (6 ft).

To avoid damage and injury, when working at a height it is advisable to use the Hilti retaining strap.

The retaining strap allows a securing cord or lanyard to be attached.

When working with the product, you must comply with national regulations for working at heights.

1. Remove the battery. → page 7

2. Insert the two tabs on the retaining strap into the slots on each side of the base.

3. Secure the retaining strap with the screws supplied.

4. Insert the battery. → page 7

6 Types of work

6.1 Setting forward or reverse rotation 6

In the middle position, the forward / reverse selector switch serves as a safety lock.

▶ Set the forward / reverse selector switch to forward or reverse rotation.
