M0158B IT | en

48 /6 0

Installation, use and maintenance

I2.2.1 IN-FIELD CALIBRATION PROCEDURE

OPERATION

Display

NONE

K900 in normal mode, not in counting mode.

LONG CAL KEY KEYING

K900 enters calibration mode, shows «CAL” and displays the calibration factor in use

instead of total. The words “Fact” and “USER” indicate which of the two factors (factory

or user) is currently in use

LONG RESET KEY KEYING

K900 shows “CAL” and the partial at zero. The meter is ready to perform in-ﬁeld cali-

bration.

DISPENSING INTO SAMPLE CONTAINER

Without pressing any buon,

start dispensing into the sample container.

Dispensing can be interrupted and started again at will. Continue dispensing until the

level of the ﬂuid in the sample container has reached the graduated area. There is no

need to reach a preset quantity.

Indicated value Real value

5 SHORT RESET KEY KEYING

K900 is informed that the calibration dispensing operation is ﬁnished.

Make sure dispensing is correctly ﬁnished before performing this operation.

To calibrate K900, the value indicated by the partial totaliser (example 155.20) must be

forced to the real value marked on the graduated sample container. In the boom le

part of the display an arrow appears (upwards and downwards), that shows the direc-

tion (increase or decrease) of the USER K FACTOR value change when the operations

6 or 7 are performed.

SHORT RESET KEY KEYING

Changes the direction of the arrow. The operation can be repeated as many times as

you wish

SHORT/LONG CAL KEY KEYING

The indicated value changes in the direction indicated by the arrow

- one unit for every short CAL key keying

- continually if the CAL key is kept pressed.

(for the ﬁrst 5 units slowly and then quickly).

If the desired value is exceeded, repeat the operations from point (6).
