This manual is the property of PIUSI S.p.A. Any reproduction, even partial, is forbidden.

Translated from Italian

K900 has a menu with which the user can configure the machine in accordance with his/her requirements.

The configuration menu consists of two sub-menus:

1 configuration menu for the main unit of measurement,

2 configuration menu of the number of impulses per unit of measurement that

are emitted by the Puls-Out output (in the relevant models).

To enter the configuration menu, proceed as follows:

1 wait until K900 is in Stand-by

2 press the CAL and RESET buttons at the same time and hold them down

until the word “Unit” and the previously-set unit of measurement appear on

the display (Litre/Litre in this example)

3 to move between sub-menus press the CAL button once quickly

CAL

CALCAL

CAL

RESET

L1 CONFIGURATION OF THE UNITS OF MEASUREMENT

The METER feature a menu with which the user can select the main measurement unit, Quarts (Qts), Pints

(Pts), Litres (Lit), Gallons (Gal); he combination of the unit of measurement of the Partial register and

that of the Totals is predefined according to the following table:

Combination no.

Unit of Measurement

Partial Register

Unit of Measurement

Totals Register

1 Litres (L) Litres (L)

2 Gallons (Gal) Gallons (Gal)

3 Quarts (Qts) Gallons (Gal)

4 Pints (Pts) Gallons (Gal)

To choose between the 4 available combinations:

1 Wait for the METER to go to Standby

CAL

RESET

Then press the CAL and RESET keys together. Keep these pressed until the

word “UNIT” appears on the screen together with the unit of measurement

set at that time (in this example Litres / Litres )

RESET

Every short press of the RESET key, the various combinations of the units of mea-

surements are scrolled as shown below:
