14 | English

Cordless Impact Wrench GDR 120-LI GDS 120-LI

Impact rate

– Setting 1 min

-1

0–1900 0–1900

– Setting 2 min

-1

0–3200 0–3200

Max. torque

, hard screwdriving application

according to ISO 5393

Nm 100 105

Machine screw diameter mm M4–M12 M4–M12

Max. screw diameter mm 8 8

Tool holder ¼" internal hexagon ∎ 3/8"

Weight according to EPTA-Procedure

01:2014

kg 1.1 1.1

Recommended ambient temperature during

charging

°C 0to+35 0to+35

Permitted ambient temperature during opera-

tion

and during storage

°C –20to+50 –20to+50

Recommended rechargeable batteries GBA 12V ... GBA 12V ...

Recommended chargers GAL 12 ...

GAX 18 ...

GAL 12 ...

GAX 18 ...

A) measured at 20–25°C with battery .

B) Limited performance at temperatures <0°C

Noise/vibration information

Noise emission values determined according to

EN62841-2-2.

Typically, the A-weighted noise level of the power tool is:

Sound pressure level 92dB(A); sound power level

103dB(A). Uncertainty K=3dB.

Wear hearing protection!

Vibration total values a

(triax vector sum) and uncertainty K

determined according toEN62841-2-2:

Impact tightening of fasteners of the maximum capacity of

the tool: a

=9.5 m/s

, K=1.5 m/s

The vibration level and noise emission value given in these

instructions have been measured in accordance with a

standardised measuring procedure and may be used to com-

pare power tools. They may also be used for a preliminary

estimation of vibration and noise emissions.

The stated vibration level and noise emission value repres-

ent the main applications of the power tool. However, if the

power tool is used for other applications, with different ap-

plication tools or is poorly maintained, the vibration level

and noise emission value may differ. This may significantly

increase the vibration and noise emissions over the total

working period.

To estimate vibration and noise emissions accurately, the

times when the tool is switched off or when it is running but

not actually being used should also be taken into account.

This may significantly reduce vibration and noise emissions

over the total working period.

Implement additional safety measures to protect the oper-

ator from the effects of vibration, such as servicing the

power tool and application tools, keeping their hands warm,

and organising workflows correctly.

Assembly

u Remove the battery from the power tool before carry-

ing out work on the power tool (e.g. maintenance,

changing tool, etc.). The battery should also be re-

moved for transport and storage. There is risk of injury

from unintentionally pressing the on/off switch.

Battery Charging

u Use only the chargers listed in the technical data. Only

these chargers are matched to the lithium-ion battery of

your power tool.

Note: The battery is supplied partially charged. To ensure

full battery capacity, fully charge the battery in the charger

before using your power tool for the first time.

The lithium-ion battery can be charged at any time without

reducing its service life. Interrupting the charging process

does not damage the battery.

The lithium-ion battery is protected against deep discharge

by the "Electronic Cell Protection (ECP)". When the battery

is discharged, the power tool is switched off by means of a

protective circuit: The application tool no longer rotates.

u Do not continue to press the On/Off switch after the

power tool has automatically switched off. The battery

can be damaged.

Removing the battery (see figure A)

To remove the battery (6), press the release button (5) and

pull the battery downwards out of the power tool. Do not

use force to do this.

Changing the Tool

u Remove the battery from the power tool before carry-

ing out work on the power tool (e.g. maintenance,

changing tool, etc.). The battery should also be re-

1 609 92A 7TL | (04.08.2022) Bosch Power Tools
