Start-up

5 START-UP

5.1 Charging the rechargeable battery (05)

NOTE

The rechargeable battery and charger

are only included in the scope of supply

of specific article numbers; refer to the

technical data at the front of these oper-

ating instructions.

The following li-ion rechargeable batteries and

charging units from AL-KO can be used:

Product Designation Item no.

Li-ion re-

chargeable

battery

B150 Li (B05-3640) 113280

Li-ion re-

chargeable

battery

B200 Li (B05-3650) 113524

Charging

unit

C130 Li (C05-4230) 113281

The rechargeable battery is partially charged.

Fully charge the rechargeable battery before us-

ing it for the first time. The rechargeable battery

can be charged in any charge status. Interrupting

charging does not damage the rechargeable bat-

tery.

NOTE

For detailed information, heed the sepa-

rate operating instructions for the re-

chargeable battery and for the charging

unit.

CAUTION!

Danger of fire during charging!

Due to heating of the charger, there is a

danger of fire if it is placed on an inflam-

mable surface and is not adequately

ventilated.

■

Always use the charger on a non-in-

flammable surface or in a non-com-

bustible environment.

■

If available: Keep the ventilation

slots free.

1. Insert the rechargeable battery (05/1) in the

charging unit (05/2) and plug the power plug

(05/3) into the power outlet. The charging

process begins and the LED for indicating the

operating status (05/4) flashes green.

2. Observe the LED (05/4). The charging pro-

cess takes approx. 1.5 – 2.0hours until fully

charged. The charging process ends auto-

matically when the rechargeable battery is

fully charged. The LED (05/4) then lights per-

manently green.

3. Disconnect the power plug (05/3) when the

LED (05/4) permanently lights green.

4. Press and hold the engaging button on the

bottom of the rechargeable battery.

5. Pull the rechargeable battery (05/1) out of the

charging unit (05/2).

Status displays on the charging unit (06)

The LED (06/1) on the charging unit indicates the

charge status of the rechargeable battery and the

operating condition of the charging unit. The sym-

bols (06/2) on the charging unit indicate these

states:

Symbol LED and charge status

LED lights green: The rechargeable

battery is fully charged.

LED flashes green: The recharge-

able battery is charging.

LED lights red: There is no recharge-

able battery in the charging unit.

LED flashes red: The rechargeable

battery is too hot and will therefore

not charge.

5.2 Determining the charge status of the

rechargeable battery (07)

There is a control panel with a pushbutton (07/1)

and LED charge status displays (07/2 to 07/5) on

the front of the rechargeable battery.

1. Press the pushbutton (07/1). The charge sta-

tus displays light according to the charge sta-

tus of the rechargeable battery.

2. To read the charge status, see section

"Charge status displays on the rechargeable

battery".

Charge status displays on the rechargeable

battery

LEDs Battery charge level

Green

(07/2)

Rechargeable battery is fully

charged, i.e. to 100 %.

Green

(07/3)

Rechargeable battery is charged

to over 50 %.
