495053_a 45

Assembly

3.4.5 Electrical safety

■

Never operate the appliance

when a lawn sprinkler is oper-

ating on the mowing area at

the same time.

■

Do not spray the appliance

with water.

■

Do not open the appliance.

4 ASSEMBLY

4.1 Unpacking the machine

1. Open the packaging carefully.

2. Carefully remove all components from the

packaging and check for transport damage.

Note:Notify your AL-KO dealer or service

partner immediately if any transport damage

is discovered.

3. Check the scope of supply, see chapter 2.1

"Scope of supply", page36.

If the appliance is going to be sent on, retain the

original packaging and accompanying docu-

ments. They will also be required for return ship-

ment.

4.2 Planning the mowing areas (01)

Location of the base station (01/1)

■

Shortest possible distance to the largest

mowing area

■

Level surface

■

Protected against direct sunlight and harsh

weather conditions

■

Connection option for power source

■

Free accessibility to the robot lawn mower

Routing the boundary cable (01)

The boundary cable must be laid in a continuous

loop in a clockwise direction.

Corridors between mowing areas (01/h)

A corridor is a narrow section in the grass surface

and can be used to connect two mowing areas.

Main area and secondary area(s) (01)

■

Main area (01/HF): This is the grass surface

on which the base station is located and

whose entire surface can be mowed auto-

matically by the appliance.

■

Secondary area (01/NF): If a grass surface

cannot be reached by the appliance from the

main area, carry the appliance to the second-

ary area by hand if necessary. Secondary ar-

eas can be processed using manual opera-

tion.

The main area and secondary areas are bounded

by the same continuous boundary cable, howev-

er.

At the specified mowing time, the appliance

moves along the boundary cable to the specified

start point and begins to mow there.

4.3 Preparing the mowing areas

1. Check that the grass surface is larger than

the area covered by the appliance. If the

grass surface is too large, an irregularly

mown lawn will result. Reduce the size of the

grass surface to be mowed if necessary.

2. Before installation of the base station and

boundary cable or start-up of the appliance:

Use a lawn mower to mow the grass surface

to a low cutting height.

3. Remove any obstacles on the grass surface

or exclude them with the boundary cable (see

chapter 4.5.3 "Excluding obstacles",

page46):

■

Flat obstacles that will be run over and

could damage the cutting blade (e.g. flat

stones, transitions from the grass surface

to the terrace or paths, plates, kerb-

stones, etc.)

■

Holes and protrusions in the grass sur-

face (e.g. molehills, burrowing holes, pine

cones, fallen fruit, etc.)

■

Steep ascents and descents of more

than 45% (24°)

■

Bodies of water (e.g. ponds, streams,

swimming pools, etc.) and their demarca-

tion to the grass surface

■

Shrubs and hedges that can become

broader

4.4 Setting up the base station(03/a)

1. Place the base station (01/1) at right angles

to the planned location of the boundary cable

as described below:

■

Level (check with spirit level)

■

Straight and level entrance and exit

■

Not arched (the charging station must not

bend or tilt during subsequent tightening

of the screw nails)
