48 Robolinho 500 E/I | 1150 SE

Start-up

■

When routing the boundary cable, the mini-

mum distance for corridors of 30cm is under-

cut (02/h).

■

The boundary cable is routed too close (i.e.

at a distance of less than 20cm) to obstacles

that cannot be driven over (02/i).

4.6 Connecting the base station to the

power source (04)

1. Place the power supply (04/4) in a dry loca-

tion that is protected against direct sunlight

and sufficiently close to the base station

(04/1).

2. Connect the low voltage cable of the power

supply (04/5) and the cable of the base sta-

tion (04/6) with each other.

3. Plug the power plug of the power supply

(04/2) into a power socket (04/3).

NOTE

We recommend connecting the power

supply to the mains supply via an earth

leakage circuit breaker (ELCB) with a

rated leakage current <30mA.

4.7 Checking the connections on the base

station (04)

1. Check that both LEDs on the front side of the

charging station (09/1) light. If not:

■

Disconnect the mains plug.

■

Check that all plug connectors of the

power source and the boundary cable

are positioned correctly and check for

damage.

Status indications of the LEDs

LEDs Operating states

Green

■

Lights up when the boundary

cable is laid correctly and the

loop is intact.

■

Flashes if a loop of the bound-

ary cable is not in order.

Yellow

■

Lights up if the power source is

intact.

5 START-UP

This chapter describes the activities and settings

that are necessary to put the appliance into oper-

ation for the first time. For all further settings, re-

fer to see chapter 7 "Settings", page50.

5.1 Charging the rechargeable battery (08)

During normal operation, the battery of the appli-

ance is regularly charged automatically.

NOTE

Fully charge the rechargeable battery

before using it for the first time. The re-

chargeable battery can be charged in

any charge status. Interrupting charging

does not damage the rechargeable bat-

tery.

The rechargeable battery can only be

charged after the appliance has been

switched on.

1. Place the appliance (08/1) in the base station

(08/3) so the contact surfaces of the appli-

ance touch the charging contacts of the base

station.

2. Switch on the appliance with .

3. The display on the appliance shows Bat-

tery is being recharged. If not: see

chapter 14 "Help in case of malfunction",

page57.

5.2 Making the basic settings

1. Open the cover flap.

2. Switch on the appliance with . The firm-

ware, code number and type are displayed.

3. In the menu for language selection, use

or to select the language and accept with

4. In the Login > Enter PIN menu, enter the

preset PIN 0000. To do so, select the digit 0

in sequence with or and respectively

confirm with . After entering the PIN, ac-

cess is enabled.

5. In the Change PIN menu:

■

Under Enter new PIN, enter a self-se-

lected new four-digit PIN. To do so, se-

lect one digit in sequence with or

and respectively confirm with .

■

Under Reenter new PIN, enter the

new PIN again. If both entries are identi-

cal, PIN changed is displayed.

6. In the Enter date menu, set the current

date (format:DD.MM.20YY). To do so, select
