495053_a 47

Assembly

NOTE

Exclusions are only necessary if they

cannot be detected by the bump sensors

of the appliance. Avoid too many or un-

necessary exclusions.

Recesses that are smaller than 6 cm

must be excluded, otherwise the appli-

ance may cause damage.

Distance from walls, fences, beds:

min.20cm(01)

The appliance moves along the boundary cable

with an offset of 20cm to the outside. Therefore,

route the boundary cable at a distance of at least

20cm from walls, fences, beds, etc.

Distance from terrace edges and paved

paths(05)

If the terrace or path edge is higher than the

grass surface, a distance of at least 20cm must

be complied with. If the edge of the terrace or

path is at the same height as the grass surface,

the cable can be routed exactly along the edge.

Distance of obstacles from the boundary

cable(01)

If the boundary cables are precisely folded up

away from the obstacle or towards the obstacle,

i.e. distance 0cm, the appliance moves beyond

the boundary cable. Do not cross the boundary

cables (02/c), but lay them parallel (01/e).

Routing the boundary cable around

corners(06)

■

For inwards going corners (06/a): Route the

boundary cable diagonally to avoid the appli-

ance becoming caught in the corner.

■

For outwards going corners with obstacles

(06/b): Route the boundary cable in a point in

order to avoid a collision of the appliance with

the corner.

■

For outwards going corners without obsta-

cles: Route the boundary cable at an angle of

90°.

4.5.4 Enclosing corridors (01/h)

In the corridor the following distances must be

complied with:

■

Total width: min. 60cm

■

Distance of the boundary cable to the edge:

20cm

■

Distance between the boundary cables: min.

30cm

4.5.5 Avoid gradients (11)

Downward slopes that are greater than 45%

must be excluded with the boundary cable (45%

= 45cm downward slopes per 1m horizontally).

The boundary cable must not be laid over a gra-

dient of more than 20%. In order to avoid prob-

lems when turning, maintain a distance of 50 cm

to the 20% gradient. If the gradient at the outer

edge of the working area is more than 20% at

any point, lay the boundary cable on the flat

ground at a distance of 20 cm from the start of

the gradient.

4.5.6 Creating loops of cable (07)

Spare loops of cable should be incorporated at

regular intervals in order to reposition the base

station or to extend the mowing area even after

the mowing area has been laid out.

Select the number of spare cable loops according

to your own judgement.

NOTE

In the case of spare cable loops, do not

form open loops.

1. Lead the boundary cable around the current

lawn peg (07/1) and then back to the previ-

ous lawn peg (07/3).

2. Then lead the boundary cable to the current

lawn peg again. This creates a loop. The ca-

bles must be close together.

3. If necessary, attach the loop to the ground in

the middle with an additional lawn peg (07/2).

4.5.7 Typical faults in cable routing (02)

■

Spare cable loops of the boundary cable are

not laid in an even, elongated loop (02/a).

■

The boundary cable is not routed properly

around corners (02/b).

■

The boundary cable is crossed over or not

routed clockwise (02/c).

■

The boundary cable is routed too imprecisely

so that edge areas of the grass surface can-

not be mowed (02/d).

■

The boundary cable is not routed lying direct-

ly next to itself when guided towards and

back from the edge to an obstacle inside the

lawn (02/e).

■

The start points are set too far away from the

base station (02/f).

■

The boundary cable is routed beyond the

edge of the grass surface (02/g).
