GB

54 Robolinho 500 E/I | 1150 SE

Transport

back, have them replaced by the AL-KO ser-

vice centre.

9.3 Replacing the cutting blades

CAUTION!

Danger of injury due to the cutting

blade

The cutting blades are very sharp and

can cause cutting injuries.

■

Wear protective gloves.

■

Make sure that parts of the body do

not get into the cutting blade.

IMPORTANT!

Damage to the appliance due to in-

correct repair

The blade plate can be damaged by the

alignment of a bent, built-in cutting

blade.

■

Do not align bent cutting blades.

■

Replace bent cutting blades by origi-

nal spare parts from AL-KO.

Worn or bent cutting blades must be replaced.

1. Switch off the appliance with .

2. Put down the appliance with the cutting

blades pointing upwards.

3. Unscrew the fastening screws.

4. Take the cutting blade out of the blade seat.

5. Clean the blade seat with a soft brush.

NOTE

The cutting blades are sharpened along

the entire length and can therefore also

be mounted rotated by 180°, which dou-

bles their runtime.

6. Replacing the cutting blades:

■

If cutting blades have not been rotated

since the initial mounting: Rotate the cut-

ting blades by 180° and insert into the

blade seat again with the sharpened side

pointing towards the appliance, and tight-

en the fastening screws again by hand.

■

If the cutting blades have already been

rotated once since the initial mounting:

Insert new cutting blades into the blade

seat again with the sharpened side point-

ing towards the appliance, and tighten

the new fastening screws by hand.

Note:It is only allowed to use original

spare parts from AL-KO.

In case of stubborn dirt that cannot be removed

with a brush, the blade plate must be replaced

because an imbalance can lead to increased

noise levels, greater wear and malfunctions.

10 TRANSPORT

To transport the appliance, proceed as follows:

1. Stop the appliance with or the stop but-

ton.

2. Switch off the appliance with .

3. Lift the appliance with both hands on the

housing:

■

Do not touch the cutting blades.

■

The cutting blades must always point

away from the body.

11 STORAGE

11.1 Storing the automatic lawn mower

The appliance must be stored over winter or

when it is to be taken out of service for an ex-

pected duration of longer than 30days.

1. Fully charge the rechargeable battery (see

chapter 5.1 "Charging the rechargeable bat-

tery (08)", page48).

2. Thoroughly clean the appliance (see chapter

9.1 "Cleaning", page53).

3. Store the appliance:

■

upright on all wheels

■

at a dry, lockable location protected from

frost

■

out of the reach of children

11.2 Storing the base station

The base station can, but does not have to be put

into storage. Storage prevents premature ageing,

however, such as fading of the colour or corro-

sion of the charging contacts.

If the base station remains outdoors:

1. Disconnect the power supply from the mains

supply and unplug from the base station.

2. Roll up the cables of the base station.

3. Store the power supply.

4. Grease the charging contacts with contact

grease.
