GB
48 Robolinho
Assembly
4.5 Installing the boundary cable
NOTE Robolinho 500/1150: If the sup-
plied boundary cable is too short, an extension
cable can be obtained from your AL-KO dealer or
service partner.
4.5.1 Connecting the boundary cable to the
base station (03/b)
1. Pull the boundary cable(03/4) out of the
packaging.
2. Remove the cover of the cable shaft (03/3)
on the connection(03/A).
3. Insulate the end of the boundary cable(03/6)
and insert into the terminal(03/7).
4. Close the terminal.
5. Lead the boundary cable through the strain
relief(03/5) out of the cable shaft with cable
reserve.
NOTE The cable reserve allows smaller
corrections to be carried out on the cable guide
later.
6. Place the cover on the cable shaft.
4.5.2 Routing the boundary cable (01)
The boundary cable can be laid on the lawn and
as much as 10 cm under the turf. The laying un-
der the turf can be carried out by the dealer.
Both variants can be combined with one another.
IMPORTANT! Danger of damaging the
boundary cable. If the boundary cable is dam-
aged or cut, the transmission of the control sig-
nals to the appliance is no longer possible. In this
case, the boundary cable must be repaired or re-
placed. The boundary cables are available from
AL-KO.
Always route the boundary cable directly on
the ground. If necessary, secure with an ad-
ditional lawn peg.
When laying the boundary cable and during
operation, protect the boundary cable from
damage.
Do not dig or scarify in the vicinity of the
boundary cable.
1. Attach the boundary cable at regular intervals
with lawn pegs or route it underground (at a
max. depth of 10cm).
2. Route the boundary cable around obstacles:
see chapter 4.5.3 "Excluding obstacles",
page48.
3. Create corridors between individual mowing
areas: see chapter 4.5.4 "Enclosing corridors
(01/h)", page49.
4. Exclude excessive upward or downward
slopes: see chapter 4.5.5 "Excluding down-
ward slopes (11)", page49.
5. Create loops of cable: see chapter 4.5.6
"Creating loops of cable (07)", page49.
6. After completing the routing of the boundary
cable, connect to the connector (03/B) of the
base station: see chapter 4.5.1 "Connecting
the boundary cable to the base station (03/
b)", page48.
4.5.3 Excluding obstacles
Depending on the surroundings of the working ar-
ea, the boundary cable must be routed at differ-
ent distances to obstacles. Use the ruler that can
be removed from the packaging to determine the
correct distance.
NOTE Exclusions are only necessary if
they cannot be detected by the bump sensors of
the appliance. Avoid too many or unnecessary
exclusions. Recesses that are smaller than 6 cm
must be excluded, otherwise the appliance may
cause damage.
Distance from walls, fences, beds:
min.20cm(01)
The appliance moves along the boundary cable
with an offset of 20cm to the outside. Therefore,
route the boundary cable at a distance of at least
20cm from walls, fences, beds, etc.
Distance from terrace edges and paved
paths(05)
If the terrace or path edge is higher than the
grass surface, a distance of at least 20cm must
be complied with. If the edge of the terrace or
path is at the same height as the grass surface,
the cable can be routed exactly along the edge.
Distance of obstacles from the boundary
cable(01)
If the boundary cables are precisely folded up
away from the obstacle or towards the obstacle,
i.e. distance 0cm, the appliance moves beyond
the boundary cable. Do not cross the boundary
cables (02/c), but lay them parallel (01/e).
Routing the boundary cable around
corners(06)
For inwards going corners (06/a): Route the
boundary cable diagonally to avoid the appli-
ance becoming caught in the corner.
