442811_a 51

Operation

Place the appliance at the starting position

(09)

1. Place the appliance at the starting position in-

side the mowing area:

■

At least 1m left and 1m in front of the

base station

■

Aligned with the front side to the bound-

ary cable

Starting the calibration movement

1. Check that there are no obstacles in the ex-

pected movement area of the appliance. The

appliance must be able to move over the

boundary cable with both front wheels. If nec-

essary, remove obstacles or lay the cable

temporarily inwards (min.35cm required).

2. Start the appliance with . The following is

shown on the display:

■

! Caution ! Starting Motors

■

Calibration , Phase [1]

During the calibration movement

To determine the signal strength inside the

boundary cable, the appliance first moves twice

straight beyond the boundary cable and then into

the base station and comes to a stop there.

■

The Calibration completed message is

shown on the display.

■

The rechargeable battery is being charged.

NOTE The appliance must come to a stop

when it moves into the base station. If the appli-

ance does not touch the contacts when it moves

into the base station, it moves further along the

boundary cable. If the appliance moves through

the base station, the calibration procedure has

failed. In this case, the base station must be bet-

ter aligned and the calibration procedure repeat-

ed.

After the calibration movement

The preset current mowing duration is displayed.

For all further settings, refer to see chapter 7

"Settings", page51.

Robolinho 700/1200/2000

NOTE To ensure proper operation and re-

duce error messages, the loop length must be

measured.
