GB
56 Robolinho
Transport
2. Put down the appliance with the cutting
blades pointing upwards.
3. Unscrew the fastening screws.
4. Take the cutting blade out of the blade seat.
5. Clean the blade seat with a soft brush.
NOTE The cutting blades are sharpened
along the entire length and can therefore also be
mounted rotated by 180°, which doubles their
runtime.
6. Replacing the cutting blades:
■
If cutting blades have not been rotated
since the initial mounting: Rotate the cut-
ting blades by 180° and insert into the
blade seat again with the sharpened side
pointing towards the appliance, and tight-
en the fastening screws again by hand.
■
If the cutting blades have already been
rotated once since the initial mounting:
Insert new cutting blades into the blade
seat again with the sharpened side point-
ing towards the appliance, and tighten
the new fastening screws by hand.
Note:It is only allowed to use original
spare parts from AL-KO.
In case of stubborn dirt that cannot be removed
with a brush, the blade plate must be replaced
because an imbalance can lead to increased
noise levels, greater wear and malfunctions.
As a rule, the clearer blades do not need to be
replaced.
10 TRANSPORT
To transport the appliance, proceed as follows:
1. Stop the appliance with or the stop but-
ton.
2. Switch off the appliance with .
3. Lift the appliance with both hands on the
housing:
■
Do not touch the cutting blades.
■
The cutting blades must always point
away from the body.
11 STORAGE
11.1 Storing the automatic lawn mower
The appliance must be stored over winter or
when it is to be taken out of service for an ex-
pected duration of longer than 30days.
1. Fully charge the rechargeable battery (see
chapter 5.1 "Charging the rechargeable bat-
tery (08)", page50)
2. Thoroughly clean the appliance (see chapter
9.1 "Cleaning", page55).
3. Store the appliance:
■
upright on all wheels
■
at a dry, lockable location protected from
frost
■
out of the reach of children
11.2 Storing the charging pole
The charging pole must be stored over winter or
when it is expected to be out of service for an ex-
pected duration of longer than 30days.
1. Disconnect the power supply from the mains
supply and unplug from the base station.
2. Removing the charging pole:
■
Unscrew both screws of the charging sta-
tion(08/5).
■
Remove the charging station from the
base station by tilting.
■
Undo the plug connection of the cables
from the base station and charging sta-
tion.
■
Close the opening of the base (08/6) with
the included winter cover (08/7).
3. Storing the charging pole:
■
at a dry, lockable location protected from
frost
■
out of the reach of children
11.3 Winter storage of the boundary cable
The boundary cable can remain in the ground
and does not need to be removed.
12 DISPOSAL
Information on the German Electrical and
Electronic Equipment Act (ElectroG)
■
Electrical and electronic appliances do
not belong in household waste, but
should be collected and disposed of
separately.
■
Used batteries or rechargeable batteries that
are not installed permanently in the old appli-
ance must be removed before disposal. Their
disposal is regulated by the battery law.
■
Owners or users of electrical and electronic
appliances are obliged by law to return them
after use.
