442811_a 55

Maintenance and care

Program Info

Shows current settings such as the total weekly

mowing time.

Failures

Shows the fault messages that last occurred with

date, time and fault code.

9 MAINTENANCE AND CARE

CAUTION! Risk of injury. Sharp-edged

and moving appliance parts can lead to injury.

■

Always wear protective gloves during mainte-

nance, care and cleaning work.

9.1 Cleaning

IMPORTANT! Danger from water. Water in

the automatic lawn mower and in the base station

leads to damage on electrical components.

■

Do not spray the automatic lawn mower and

base station with water.

Clean the automatic lawn mower

CAUTION! Danger of injury due to the

cutting blade. The cutting blades are very sharp

and can cause cutting injuries.

■

Wear protective gloves.

■

Make sure that parts of the body do not get

into the cutting blade.

Once a week, carry out the following:

1. Switch off the appliance with .

2. Wipe off the surface of the housing with a

broom, a brush, a damp cloth or a fine

sponge.

3. Brush off the underside, mower deck and cut-

ting blade with a brush.

4. Check the cutting blade for damage. If neces-

sary, replace the following: see chapter 9.3

"Replacing the cutting blades", page55.

Cleaning the base station

1. Regularly remove grass residues and leaves

or other objects out of the base station.

2. Wipe off the surface of the base station with

a damp cloth or a fine sponge.

9.2 Regular checks

General checks

1. Once a week, check the whole Installation for

damage:

■

Machine

■

Base station

■

Boundary cable

■

Power supply

2. Replace defective parts by original spare

parts from AL-KO or have them replaced by

an AL-KO service centre.

Check the rollers can move freely

Once a week, carry out the following:

1. Carefully remove grass residues and soiling

from the areas around the rollers. Use a

broom and cloth for this.

2. Check that the rollers run freely and that they

can be steered.

Note:If the rollers do not move freely or can-

not be steered, have them replaced by an

AL-KO service centre.

Check the contact surfaces on the automatic

lawn mower

1. Use a cloth to remove soiling and then lightly

grease with contact grease.

Check the charging contacts of the base

station

1. Disconnect the mains plug.

2. Press the charging contacts in the direction

of the base station and release them. The

charging contacts must spring back into the

initial position.

Note:If the charging contacts do not spring

back, have them replaced by the AL-KO ser-

vice centre.

9.3 Replacing the cutting blades

CAUTION! Danger of injury due to the

cutting blade. The cutting blades are very sharp

and can cause cutting injuries.

■

Wear protective gloves.

■

Make sure that parts of the body do not get

into the cutting blade.

IMPORTANT! Damage to the appliance due

to incorrect repair. The blade plate can be dam-

aged by the alignment of a bent, built-in cutting

blade.

■

Do not align bent cutting blades.

■

Replace bent cutting blades by original spare

parts from AL-KO.

Worn or bent cutting blades must be replaced.

1. Switch off the appliance with .
