TECHNICAL PASSPORT ENGLISH

Gas hob

Figure 3Figure 4

Figure 1Figure 2

UPPER TRAY

SILICONE SEAL

WORKTOP SURFACE

CONNECTION CLIP

SCREW

INSTALLATION OF THE BUILT

IN COOKER 400 SERIES

Worktop cutting measure is given in Figure 7 for placing the cooker. Into the

worktop cut to these measures, place the cooker of which the initial preparations

were performed.

If you will use the cooker on the built-in oven, then comply with the Figures

8and 9 for proper clearance between the oven and cooker to allow air circulation.

Please place the silicone seal along the edges of the cooker (Figure 1). Finally,

you. should x it on the lower edges of the work surface by means of clamps and

screws (Figure 2).
