WARNING: Gas hose and electric connection of the appliance should not

pass next to hot areas such as back of the appliance. Gas hose should be

connected by making wide angle turns against breaking possibility. Movement

of appliance whose gas connection is made may cause gas leakage.

For natural gas connection;

Transformation from natural gas to LPG and from LPG to natural gas

1. Turn off gas and electricity of the cooktop. If your cooktop is hot, wait

for cooling down.

2. For injector change, use a screwdriver whose edge is as the gure 1.

3. As seen in gure 2, demount burner lid and burner of the cooktop and

ensure visibility of injector.

4. Remove injector by turning as shown in gure 3 with screwdriver and

replace it with a new one.

Correct Incorrect Correct Correct

Main gas pipe

Gasket

Nut

Natural gas

Connection hose

WARNING: Natural gas connection should

be done by authorized service.

For natural gas connection, place gasket

in the nut at the edge of natural gas connection

hose. To install the hose on main gas pipe,

turn the nut. Complete the connection by

making gas leakage control.

Figure 1

Figure 2

Figure 3
