Model DG1022Z DG1032Z DG1062Z

Channel 2 2 2

Max Frequency 25 MHz

30 MHz 60 MHz

Sample Rate 200 MSa/s

Waveform

Basic Waveform Sine, Square, Ramp, Pulse, Noise

Built-in Arbitrary Waveform

160 kinds, including Sinc, Exponential Rise, Exponential Fall, ECG, Gauss, HaverSine, Lorentz,

Dual-Tone, etc.

Frequency Characteristics

Sine 1 μHz to 25 MHz 1 μHz to 30 MHz 1 μHz to 60 MHz

Square 1 μHz to 25 MHz 1 μHz to 25 MHz 1 μHz to 25 MHz

Ramp 1 μHz to 500 kHz

1 μHz to 500 kHz

1 μHz to 1 MHz

Pulse 1 μHz to 15 MHz 1 μHz to 15 MHz 1 μHz to 25 MHz

Harmonic 1uHz to 10 MHz 1 μHz to 10 MHz 1uHz to 20 MHz

Noise (-3dB) 25 MHz bandwidth 30 MHz bandwidth 60 MHz bandwidth

Arbitrary Waveform 1 μHz to 10 MHz 1 μHz to 10 MHz 1 μHz to 20 MHz

Resolution 1 μHz

Accuracy ±1 ppm of the setting value, 18

℃

to 28

℃

Sine Wave Spectrum Purity

Harmonic Distortion

Typical (0 dBm)

DC-10 MHz (included): <-65 dBc

10 MHz to 30 MHz (included): <-55 dBc

30 MHz to 60 MHz (included): <-50 dBc

Total Harmonic Distortion <0.075% (10 Hz to 20 kHz, 0 dBm)

Spurious (non-harmonic)

Typical (0 dBm)

≤10 MHz: <-70 dBc

>10 MHz: <-70 dBc + 6 dB/octave

Phase Noise

Typical (0 dBm, 10 kHz offset)

10 MHz: <-125 dBc/Hz

Signal Characteristics

Square

Rise/Fall Time

Typical (1 Vpp)

<10ns

Overshoot

Typical (100 kHz, 1 Vpp)

≤5%

Duty Cycle 0.01% to 99.99% (limited by the current frequency setting)

Non-symmetry 1% of the period + 5 ns

Jitter (rms)

Typical (1 Vpp)

≤5 MHz: 2 ppm + 200 ps

> 5 MHz: 200 ps

Ramp

Linearity ≤1% of peak output (typical, 1 kHz, 1 VPP, 100% symmetry)

Symmetry 0% to 100%

Pulse

Pulse Width 16ns to 999.999 982 118ks (limited by the current frequency setting)

Duty Cycle 0.001% to 99.999% (limited by the current frequency setting)

Rising/Falling Edge ≥10 ns (limited by the current frequency setting and pulse width setting)

Overshoot

Typical (1 Vpp)

≤5%

Jitter (rms)

Typical (1 Vpp)

≤5 MHz 2 ppm + 200 ps

> 5 MHz 200 ps

Arbitrary Waveform

Waveform Length

2Mpts (std.)

16Mpts (opt.)

8Mpts (std.)

16Mpts (opt.)

8Mpts (std.)

16Mpts (opt.)

Specications

All the specications can be guaranteed if the following two conditions are met unless where noted.

· The generator is within the calibration period and has performed self-calibration.

· The generator has been working continuously for at least 30 minutes under the specied temperature (18

℃

~ 28

℃

All the specications are guaranteed unless those marked with “typical”.

RIGOL
