Vertical Resolution 14 bits

Sample Rate 200MSa/s

Min Rise/Fall Time

Typical (1 Vpp)

<10 ns

Jitter (rms)

Typical (1 Vpp)

≤5 MHz: 2 ppm + 200 ps

> 5 MHz: 200 ps

Editing Mode Point Edit, Block Edit, Insert Waveform

Harmonic Output

Harmonic Order ≤8

Harmonic Type Even Harmonic, Odd harmonic, Order Harmonic, User

Harmonic Amplitude The amplitude of each order of harmonic can be set

Harmonic Phase The phase of each order of harmonic can be set

Output Characteristics

Amplitude (into 50 Ω)

Range

≤10 MHz: 1.0 mVpp to 10 Vpp

≤30 MHz: 1.0 mVpp to 5.0 Vpp

≤60 MHz: 1.0 mVpp to 2.5 Vpp

Accuracy

Typical (1 kHz sine, 0 V offset, >10 mVpp, auto)

±(1% of the setting value) ±1 mV

Flatness

Typical (sine, 2.5 Vpp)

≤10 MHz: ±0.1 dB

≤60 MHz: ±0.2 dB

Unit Vpp, Vrms, dBm

Resolution 0.1mVpp or 4 digits

Offset (into 50 Ω)

Range (Peak ac+dc) ±5Vpk ac+dc

Accuracy ±(1% of the setting value + 5mV + 0.5% of the amplitude)

Waveform Output

Output Impedance 50 Ω (typical)

Protection Short-circuit protection, automatically disable the waveform output when overload occurs

Modulation Characteristics

Modulation Type AM, FM, PM, ASK, FSK, PSK, PWM
