Trigger Characteristics
Trigger Input
Level TTL-compatible
Slope Rising or falling (selectable)
Pulse Width >100ns
Latency
Sweep: <100 ns (typical)
Burst: <300 ns (typical)
Trigger Output
Level TTL-compatible
Pulse Width > 60 ns (typical)
Maximum Frequency 1 MHz
Two-channel Characteristics - Phase Offset
Range 0° to 360°
Waveform Phase Resolution 0.03°
Reference Clock
External Reference Input
Lock Range 10 MHz ± 50 Hz
Level 250 mVpp to 5 Vpp
Lock Time < 2 s
Input Impedance (Typical) 1 kΩ, AC coupling
Internal Reference Output
Frequency 10 MHz ± 50 Hz
Level 3.3 Vpp
Input Impedance (Typical) 50 Ω, AC coupling
Sync Output
Level TTL-compatible
Impedance 50 Ω, nominal value
Overvoltage Protection
Occurred when:

The instrument amplitude setting is greater than 2Vpp or the output offset is greater than |2V
DC
| and the input voltage is greater
than ±11.5 × (1 ± 5%)V (<10kHz).

The instrument amplitude setting is lower than or equal to 2Vpp or the output offset is lower than or equal to |2V
DC
| and the
input voltage is greater than ±3.5 × (1 ± 5%)V (<10kHz).
General Specications
Power Supply
Power Voltage 100 V to 240 V (45 Hz to 440 Hz)
Power Consumption Lower than 40 W
Fuse 250 V, T3.15 A
Display
Type 3.5-inch TFT LCD
Resolution 320 horizontal × RGB × 240 vertical resolution
Color 16 M color
Environment
Temperature Range
Operating: 0
℃
to 50
℃
Non-operating: -40
℃
to 70
℃
Cooling Method Fan cooling
Humidity Range
Lower than 30
℃
: ≤95% relative humidity
30
℃
to 40
℃
: ≤75% relative humidity
40
℃
to 50
℃
: ≤45% relative humidity
Altitude
Operating: below 3000 meters
Non-operating: below 15,000 meters
Mechanical
Dimensions (W×H×D) 261.5 mm × 112 mm × 318.4 mm
Weight
Without Package: 3.2 kg
With Package: 4.5 kg
Interfaces USB Host, USB Device, LAN
IP Protection IP2X
Calibration Interval 1 year recommended calibration interval
6
