Source Internal
Modulating Waveform Sine, Square, Ramp, Noise, Arb
Key Frequency 2mHz to 1MHz
OSK
Carrier Waveform Sine
Source Internal/External
Oscillation Time 8ns to 499.75μs
Key Frequency 2mHz to 1MHz
PWM
Carrier Waveform Pulse
Source Internal/External
Modulating Waveform Sine, Square, Ramp, Noise, Arb
Width Deviation 0% to 100% of pulse width
Modulating Frequency 2mHz to 50KHz
External Modulation Input
Maximum Input Range 75mVRMS to ±2.5Vac+dc
Input Bandwidth 5MHz
Input Impedance 1kΩ
Burst Characteristics
Carrier Waveform Sine, Square, Ramp, Pulse, Noise, Arb (except DC)
Carrier Frequency 2mHz to 100MHz 2mHz to 100MHz 2mHz to 60MHz
Burst Count 1 to 1000000 or Innite
Start/Stop Phase 0° to 360°
Internal Period 2μs to 500s
Gated Source External Trigger
Trigger Source Internal, External or Manual
Trigger Delay 0ns to 85s
Sweep Characteristics
Carrier Waveform Sine, Square, Ramp, Arb (except DC)
Type Linear, Log or Step
Direction Up or Down
Start/Stop Frequency 1μHz to 200MHz 1μHz to 160MHz 1μHz to 100MHz 1μHz to 60MHz
Sweep Time 1ms to 300s
Hold/Return Time 0ms to 300s
Trigger Source Internal, External or Manual
Mark Falling edge of Sync signal (programmable)
Counter
Function Frequency, Period, Positive/Negative Pulse Width, Duty Cycle
Frequency Resolution 7 digits/second (Gate Time =1s)
Frequency Range 1μHz to 200MHz
Period Measurement 5ns to 16 days
Voltage Range and Sensitivity (Non-modulating signal)
DC Coupling
DC Offset Range ±1.5V
DC
Input Attenuation:
OFF
1μHz to 100MHz
50mVRMS to ±2.5Vac +
dc
100MHz to 200MHz
100mVRMS to ±2.5Vac +
dc
AC Coupling
1μHz to 100MHz 50mVRMS to ±2.5Vpp
100MHz to 200MHz 100mVRMS to ±2.5Vpp
