Pulse Width and Duty Cycle Measurements

Frequency/Amplitude Range 1μHz to 25MHz

50mVRMS to

±2.5Vac + dc

DC Coupling,

Input Attenuation:

OFF

Pulse Width

Minimum ≥20ns

Resolution 2ns

Duty Cycle Range (Display) 0% to 100%

Input Characteristics

Input Range Breakdown Voltage

±7Vac + dc (Attenuation:

OFF)

Input Impedance =

1MΩ

±70Vac + dc (Attenuation:

OFF)

5Vrms

Input Impedance =

50Ω

Input Adjustment

Input Attenuation ON: ×10; OFF: ×1

Input Impedance 50Ω 1MΩ

Coupling Mode AC DC

HF Reject

ON: input bandwidth = 250kHz; OFF: input

bandwidth = 225MHz

Input Trigger

Trigger Level Range -2.5V to +2.5V

Trigger Sensitivity Range

0% (140mV hysteresis voltage) to 100% (2mV

hysteresis voltage)

Gate Time

GateTime1 1ms

GateTime2 10ms

GateTime3 100ms

GateTime4 1s

GateTime5 10s

GateTime6 >10s

Trigger Characteristics

Trigger Input

Level TTL-compatible

Slope Rising or falling (selectable)

Pulse Width >50ns

Latency

Sweep: <100ns (typical)

Burst: <300ns (typical)

Trigger Output

Level TTL-compatible

Pulse Width >60ns (typical)

Maximum Rate 1MHz

Clock Reference

Phase Offset

Range 0° to 360°

Resolution 0.03°

External Reference Input

Lock Range 10MHz ± 50Hz

Level 250mVpp to 5Vpp

Lock Time <2s

Input Impedance (Typical) 1kΩ, AC coupling

Internal Reference Output

Frequency 10MHz ± 50Hz

Level 3.3Vpp

Input Impedance (Typical) 50Ω, AC coupling
