Sync Output

Level TTL-compatible

Impedance 50 Ω, nominal

Programming Time (Typical)

USB 2.0 LAN

Function Variation 500ms 510ms

Frequency Variation 50ms 50ms

Amplitude Variation 300ms 310ms

Select User Arbitrary Waveform 500ms 510ms

General Specications

Power

Power Voltage 100V to 240V, 45Hz to 440Hz

Power Consumption Less than 50W

Fuse 250V, T2A

Display

Type 7-inch TFT LCD

Resolution 800 Horizontal × RGB × 480 Vertical Resolution

Color 16M color

Environment

Temperature Range

Operating: 10

℃

to 40

℃

Non-Operating: -20

℃

to 60

℃

Cooling Method Cooling by fans compulsively

Humidity Range

Less than 35

℃

: ≤90% Relative Humidity

℃

to 40

℃

: ≤60% Relative Humidity

Altitude

Operating: Less than 3000 meters

Non-Operating: Less than 15000 meters

Mechanical

Dimensions (W × H × D) 313mm × 160.7mm × 116.7mm

Weight

Without package: 3.2kg

With package: 4.5kg

Interface

USB Host, USB Device, LAN

IP Protection

IP2X

Calibration Interval

Recommend 1 year for standard interval
