115

www.sames-kremlin.com

Airmix

spraying & equipment

Catalog V5.3

General informations

Spray gunsMachines & Controllers PumpsAccessoriesGeneral informations

Praticals pages

Mesh

(number of holes in 25,4 mm)

Micron

N° ltre

(mesh opening in µm)

10 1480 –

16 975 –

20 750 30

25 630 25

30 500 20

40 375 –

45 360 15

50 300 12

60 238 –

70 210 8

80 175 6

100 149 –

140 100 4

170 90 3

200 74 –

250 60 –

270 50 2

325 40 1

400 35 –

Filtration equivalence

Pressure loss in uid hoses

Pressure drop is the resistance that prevents material from moving forward in the pipe. Two pipe

variables influence this resistance : the (inside/internal) diameter and the pipe length. The pump

will generate a pressure, strong enough to move the fluid material through the pipe (or hose) to the

material pipe outlet. This pressure must be enough to overcome the original pressure drop.

While it is hard to reduce the pipe length, it is relatively easy to select an appropriate internal pipe

diameter.

PRESSURE DROP CALCULATION

Pressure

loss (bar/m) =

6.9 x Flow (l/min)x Viscosity (cps)

Pressure

loss (psi/Ft) =

2.73 x Flow (gpm) x Vicosity (cps)

(int dia in mm) D

(int dia in inches)

FLOW RATE CALCULATION

Flow (l/min) =

Pressure loss (bar/m)x D

(int dia in mm)

Flow (gpm) =

Pressure loss (psi/Ft)x D

(int dia in inches)

6.9 x Viscosity (cps) 2.73 x Viscosity (cps)

PIPE DIAMETER CALCULATION

Interior

Dia (mm) =

6.9 x Flow (l/min) x Viscosity (cps)

Interior Dia (in) =

2.73 x Flow (gpm)x Viscosity (cps)

Pressure Loss (bar/m) Pressure loss (psi/Ft)

4 4
