16 English
Technical data
Subject to technical modifications.
EU Declaration of Conformity
We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements in the EU Directives, both in its basic design
and construction as well as in the version placed in cir-
culation by us. This declaration is invalidated by any
changes made to the machine that are not approved by
us.
Product: High-pressure cleaner
Type: 1.520-xxx
Currently applicable EU Directives
2000/14/EC
2006/42/EC (+2009/127/EC)
2011/65/EU
2014/30/EU
Harmonised standards used
EN 60335-1
EN 60335-2-79
EN 55012: 2007 + A1: 2009
EN IEC 63000:2018
EN 62233: 2008
Applied conformity evaluation method
2000/14/EG: Annex V
Sound power level dB(A)
HD 4/8 Classic
Measured: 89.8
Guaranteed: 92
HD 4/10 X Classic
Measured: 91.3
Guaranteed: 93
The undersigned act on behalf and under the power of
attorney of the company management.
Documentation supervisor:
S. Reiser
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Ph.: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2019/01/01
HD 4/8 Classic HD 4/10 X Classic
Electrical connection
Voltage V 220 - 240 220 - 240
Phase ~ 1 1
Frequency Hz 50 50
Power rating kW 1.4 1.8
Degree of protection IPX5 IPX5
Power protection (slow-blowing) A 10 10
Extension cable, 30 m mm
2
2.5 2.5
Water connection
Feed pressure (max.) MPa (bar) 1.0 (10) 1.0 (10)
Input temperature (max.) °C 40 40
Input amount (min.) l/h (l/min) 480 (8.0) 480 (8.0)
Suction height (max.) m 1.0 1.0
Device performance data
Nozzle size of standard nozzle 33 28
Water flow rate l/h (l/min) 400 (6.7) 400 (6.7)
Operating pressure MPa (bar) 8 (80) 10 (100)
Operating pressure (max.) MPa (bar) 12 (120) 14.5 (145)
High-pressure gun recoil force N 14.2 15.4
Dimensions and weights
Weight (without accessories) kg 16 19
Length x width x height mm 350 x 330 x 880 350 x 330 x 880
Determined values in acc. with EN 60335-2-79
High-pressure gun hand-arm vibration value m/s
2
3.1 4.4
Uncertainty K m/s
2
1.5 1.5
Sound pressure level L
pA
dB(A) 77 78
Uncertainty K
pA
dB(A) 2.5 2.5
Sound power level L
WA
+ K uncertainty
WA
dB(A) 92 93
Chairman of the Board of Management
Director Regulatory Affairs & Certification
H. Jenner
S. Reiser
