English 15

Device description

Overview of the unit

See graphics page

1 Hubcap

2 Nozzle holder

3 Skid

4 Type plate

5 Nozzle storage for triple nozzle

6 Transport retainer for surface cleaner

7 Push handle lock

8 Push handle, bottom (pushed in)

9 Push handle, top (pulled out)

10 High-pressure nozzle

11 High-pressure nozzle marking

12 EASY!Lock spray lance

13 EASY!Force high-pressure gun

14 Safety latch

15 Trigger

16 Safety lever

17 EASY!Lock high-pressure hose

18 Hose storage compartment

19 Cable clips

20 Spray lance holder without a clamp

21 Rubber band (not in devices with a hose reel)

22 Nozzle storage compartment for rotary nozzle (rota-

ry nozzle only included in the scope of delivery of

the "Plus" variant)

23 Spray lance holder with a clamp for transport

24 Power switch

25 Handle

26 EASY!Lock high-pressure connection

27 Handle

28 Water connection

29 Detergent suction hose with filter and detergent

dosing unit

30 sieve

31 Hose spout

32 Union nut

33 Crank

34 Hose reel

Colour coding

 Control elements for the cleaning process are yel-

low.

 Control elements for maintenance and servicing are

light grey.

Installation

Fastening the hubcaps

 Fasten the hubcaps.

Installing accessories

Note

The EASY!Lock system connects components quickly

and safely via a single turn of the quick-release thread.

1. Fit the high-pressure nozzle onto the spray lance

with the marking facing upwards.

2. Tighten the high-pressure nozzle hand-tight

(EASY!Lock).

3. Connect the spray lance to the high-pressure gun

and hand-tighten (EASY!Lock).

4. Release the push handle lock.

5. Pull the push handle out to the end position.

For devices without a hose reel:

6. Connect the high-pressure hose to the high-pres-

sure gun and high-pressure connection of the de-

vice and tighten hand-tight (EASY!Lock).

For devices with a hose reel:

7. Lay the high-pressure hose on the ground in a

straight line.

8. Insert the crank into the hose reel shaft and latch in-

to position.

9. Turn the crank clockwise and wind the high-pres-

sure hose onto the hose reel in evenly distributed

layers.

10. Connect the high-pressure hose to the high-pres-

sure gun and hand-tighten (EASY!Lock).

Electrical connection

 DANGER

Failure to disconnect the mains

Risk of injury from electric shock

Use a plug to connect the device to the mains grid. Per-

manent connection to the mains grid is prohibited. The

plug is used for disconnection from the mains.

1. Unwind the mains cable and place on the ground.

2. Plug the mains plug into the socket.

Water connection

Connection to a water line

몇 WARNING

Return flow of dirty water into the drinking water

network

Health risk

Observe the regulations of your water supply company.

According to applicable regulations, the device must

never be used with the drinking water network without a

system separator. Use a system separator from

KÄRCHER or a system separator as per EN 12729
