6 English 2215656

*2215656*

3.6 Selecting the crimping / pressing die

A table to assist with selecting the type of crimping / pressing die to be used can be found at the end of

these operating instructions.

4 Technical data

NCR 120 PC-A22

Rated voltage

21.6 V

Weight in accordance with EPTA Procedure 01 including batteryB22⁄8.0

7.5 kg

Crimping / pressing time

8 s … 9 s

Max. crimping / pressing force

108 kN

Max. permissible crimping capacity

• 750 MCM

(400 mm²) Cu

• 750 MCM

(300 mm²) Al

Storage temperature

−20 ℃ … 70 ℃

Ambient temperature for operation

−17 ℃ … 60 ℃

4.1 Noise information and vibration values in accordance with EN 60745

The sound pressure and vibration values given in these instructions were measured in accordance with a

standardized test and can be used to compare one power tool with another. They can also be used for a

preliminary assessment of exposure. The data given represents the main applications of the power tool.

However, if the power tool is used for different applications, with different accessory tools, or is poorly

maintained, the data can vary. This can significantly increase exposure over the total working period. An

accurate estimation of exposure should also take into account the times when the tool is switched off, or

when it is running but not actually being used for a job. This can significantly reduce exposure over the

total working period. Identify additional safety measures to protect the operator from the effects of noise

and/or vibration, for example: Maintaining the power tool and accessory tools, keeping the hands warm,

organization of work patterns.

Noise values

Sound power level (L

)

80 dB(A)

Uncertainty for the sound power level (K

)

2.5 dB(A)

Emission sound pressure level (L

)

70 dB(A)

Uncertainty for the sound pressure level (K

)

2.5 dB(A)

Vibration values

Total vibration (during operation) (a)

2.5 m/s²

Uncertainty (K)

1.5 m/s²

4.2 Battery

Battery operating voltage

21.6 V

Ambient temperature for operation

−17 ℃ … 60 ℃

Storage temperature

−20 ℃ … 40 ℃

Battery charging starting temperature

−10 ℃ … 45 ℃
