6 English 2207121

*2207121*

3.5 Items supplied

Crimping / pressing and cutting tool, operating instructions.

Other system products approved for use with this product can be found at your local Hilti Store or at:

www.hilti.group

3.6 Selecting the crimping / pressing die

A table to assist with selecting the type of crimping / pressing die to be used can be found at the end of

these operating instructions.

4 Technical data

NUN 054 IE-A22

Rated voltage

21.6 V

Weight in accordance with EPTA Procedure 01 including B22⁄8.0 battery

2.6 kg

Crimping time

≈ 4 s

Max. crimping / pressing force

53 kN

max. cutting capacity (outside diameter) (NCT J

CUAL cutting jaws)

Cu cable

33 mm

Al cable

33 mm

max. cutting capacity (outside diameter) (NCT J

ACSR cutting jaws)

Steel-reinforced Al ca-

ble

20.5 mm

Steel rope / guy wire

(EHS)

7 mm

Max. permissible crimping capacity Cu/Al standard con-

nector

240 mm²

Cu/Al fine-wire stan-

dard connector

185 mm²

Storage temperature

−20 ℃ … 70 ℃

Ambient temperature for operation

−17 ℃ … 60 ℃

4.1 Noise and vibration values in accordance with EN 60745

The sound pressure and vibration values given in these instructions were measured in accordance with a

standardized test and can be used to compare one power tool with another. They can also be used for a

preliminary assessment of exposure. The data given represents the main applications of the power tool.

However, if the power tool is used for different applications, with different accessory tools, or is poorly

maintained, the data can vary. This can significantly increase exposure over the total working period. An

accurate estimation of exposure should also take into account the times when the power tool is switched

off, or when it is running but not actually being used for a job. This can significantly reduce exposure over

the total working period. Identify additional safety measures to protect the operator from the effects of noise

and/or vibration, for example: maintaining the power tool and accessory tools, keeping the hands warm,

organization of work patterns.

Noise values

Sound (power) level (L

)

80 dB(A)

Uncertainty for the sound power level (K

)

2.5 dB(A)

Emission sound pressure level (L

)

70 dB(A)

Uncertainty for the sound pressure level (K

)

2.5 dB(A)

Vibration values

Total vibration (during operation) (a)

2.5 m/s²

Uncertainty (K)

1.5 m/s²
