8 English 2207121

*2207121*

7. Rotate the tool head to the desired working position.

The tool head can be rotated much more easily when not under pressure.

5.6 Removing the crimping / pressing or cutting jaws 3

WARNING

Risk of injury! Unintentional starting.

▶ Remove the battery before fitting, changing or removing the crimping /pressing or cutting jaws.

1. Remove the battery and rotate the head of the tool to the outset position.

2. Press the locking pins.

3. Rotate the locking pins counterclockwise as far as they will go.

4. Pull out the locking pins.

5. Remove the crimping / pressing or cutting jaws toward the nose of the tool.

5.7 Inserting the crimping die (only for crimping jaws with crimping dies) 4

WARNING

Risk of injury! Unintentional starting.

▶ Remove the battery before fitting, changing or removing the crimping / pressing die.

Never operate the tool without a crimping / pressing die in place.

1. Remove the battery.

2. Select a suitable crimping die. Push the two halves of the crimping / pressing die in until they engage.

5.8 Removing the crimping die (only for crimping jaws with crimping dies) 5

WARNING

Risk of injury! Unintentional starting.

▶ Remove the battery before fitting, changing or removing the crimping / pressing die.

1. Remove the battery.

2. Pull back the locking mechanism and remove the two halves of the crimping die.

5.9 Changing the cutting edges 6

WARNING

Risk of injury! Unintentional starting.

▶ Remove the battery before inserting, changing or removing cutting edges.

1. Remove the battery.

2. Unscrew the cutting edge securing screws.

3. Remove the cutting edges by pulling them out toward the front end of the tool.

4. Insert the new cutting edges in the tool.

5. Tighten the cutting edge securing screws.
