Zalman CNPS7000C-Cu LED [5/8] Installation
![Zalman CNPS7500-Cu LED [5/8] Installation](/views2/1111022/page5/bg5.png)
4
.COM
1) Intel Socket Installation
① Install the Clip Support to the motherboard
5. Installation
② Clear off any particles or residue from the CPU’s surface then spread
a thorough layer of Thermal Grease on the CPU and the base of the
cooler.
▶ Please make note of the Lever Slot’s direction when
installing the Clip Support.
Caution
Lever
Slot
Nut
Washer
Bolt
Clip Support
M/B
