443093_c 21

Assembly

■

Keep the working area free from material to

be shredded and other objects – danger of

stumbling.

■

The user of the machine is responsible for

accidents involving other persons or their

property.

■

Ensure good lighting of the working area.

Operating times:

■

When operating in residential areas, observe

country-specific and communally permitted

operating times according to the regulations

on noise pollution.

■

Work with the machine in daylight or with

good lighting only.

Operation:

■

Do not reach into the hopper or feed chute

during operation!

■

The cutting disk after-runs after the machine

is switched off!

■

Only put the machine into operation when as-

sembly has been completed.

■

Always perform a visible inspection prior to

using the machine. The machine must be in a

safe operating condition.

■

Never work alone.

■

Immediately renew damaged or worn parts.

■

Only use the machine if it is in the technical

condition stipulated by the manufacturer.

■

Do not undertake shredding work in the rain,

snow, stormy weather or during thunder-

storms (danger of lightning!). Do not use the

shredder in wet or damp surroundings.

■

Do not deactivate safety and/or protective de-

vices on the machine.

■

Always ensure that the machine is stable be-

fore starting work.

■

Never transport the shredder with the motor

running.

■

Never transport the shredder with open or

unlocked shredder upper section.

■

Switch the motor off, wait for the cutting disk

to stop moving, and disconnect the machine

from the mains connection prior to moving

the machine.

■

When moving the shredder, only transport it

using its handle.

■

Always ensure a stable stance when working.

Do not bend forward too far.

■

Do not feed the shredder from an elevated

position.

■

Always disconnect the shredder from the

mains power supply when not in use.

In the event of a malfunction or accident:

■

Immediately disconnect the mains plug from

the mains if the mains cable has been dam-

aged or severed!

■

If a foreign object is drawn in or in the event

of unusual noises or vibrations, immediately

switch off the shredder and disconnect it from

the mains. Then proceed as follows:

■

Inspect the damage.

■

Refasten loose parts, e.g. tighten screws.

■

Have all damaged parts exchanged or re-

paired by our customer service.

5 ASSEMBLY

CAUTION! Danger of injury if the ma-

chine is incomplete! Incomplete machines can

lead to injuries and damage to the machine!

■

Do not operate the machine until it has been

fully assembled.

5.1 Mounting the chassis (03)

1. Push (03/a) the ends of the bases (03/1) into

the frame connection (03/2).

2. Position the axle tube (03/3) between the

bases.

5.2 Mounting the transport wheels (04)

1. Slide the wheel shaft (04/1) into the base.

2. Next, slide a large washer 10x20x1.5 (04/2)

and the bushing (04/3) onto the shaft.

3. Afterwards, slide the transport wheel (04/4)

onto the bushing.

4. Place the washer 8x20x1.5 (04/5) onto the

thread and secure the transport wheel using

an M8 nut (04/6).

5. Press the wheel cap (04/7) onto the transport

wheel.

6. Fit the opposite transport wheel in the same

sequence.

5.3 Mounting the pedestals (05)

1. Turn the transport frame around.

2. Attach the pedestals (05/a) to the transport

frame using the screws (05/1).
