11
The complete set is shown on the package. During un-
packing the device, check the complete set.
2. DISCONNECTION OF THE DROP HORN
ATTENTION!
At the time of installation of the device is recommend-
ed Wear safety glasses. Loosen the nut (1) on the top of
the water trap (4) with a pipe wrench (Fig. 3.1). relative
humidity not more than 80%. Loosen the nut (2) on the
top of the extension pipe. Remove the extension pipe.
Loosen the nut (3) at the bottom of the washing ange.
Push the washing ange upwards through drain hole of
the sink and remove it (Fig. 3.2).
CLEAN THE WASH FAN WRAPPING PLACE FROM THE
SEALANT OR THE GARBAGE.
NOTE: It may be necessary to expand the drain hole for
installation ange fastening disposer. Equipment for
extending the drainage hole is purchased separately.
3. DISASSEMBLY OF THE ASSEMBLY UNIT
Turn over the assembly (Fig.4.1) and loosen the three
xing screws (1) The access to the ring (2).
Disconnect the retaining ring from the ange with a
screwdriver. Now the assembly unit can be disassem-
bled.
4. ATTACHING THE FIXING ASSEMBLY TO WASHING
Fig.5.1.
1. Install one or two rubber gaskets (2) under the wash-
ing ange (1). Make sure that The drainage hole is not
clogged, and set to ange washer / gasket. In order to
The ange of the sink became in place, you need to
crush it with a heavy load. (To avoid scratches, use a
towel as a lining.)
2. Put the second rubber part on the bottom of the
kitchen sink a gasket (2), a cardboard gasket (optional)
(3) and a metal support ring (4) (at side up).
3. While holding the second rubber gasket, cardboard
padding (optional) and a metal support ring, put the
mounting ring (5) on the ange of the sink so that it
aligned with the support ring.
4. Pressing tightly to the bottom of the sink rubber gas-
ket, cardboard gasket, support ring and mounting ring,
slide the snap ring (7) onto the ange of the sink so that
it snaps into the ange groove.
5. Tighten the three xing screws (6) to The xing as-
sembly was tight and evenly pressed to the sink.
5. CLEANING THE DRAIN PIPE
If you do not clean the drain pipe, it can clog.
1. Remove the water trap. (Fig.6.1)
2. Using a cleaner, remove all solid precipitation in the
horizontal part of the drainage pipes, moving with side
of the siphon towards the main pipe.
IF THE DISHWASHER WILL NOT BE CONNECTED TO
THE DISPOSER, GO TO PART 7 OF THIS INSTRUCTION
6. CONNECTING THE DISHWASHER MACHINES AND
TRANSFER CONNECTION
If the sink is full of liquid it can be discharged into the
disposer through the inlet in its upper parts. (Fig. 7.2)
On all models inside the intake pipe there is partition.
The partition must be removed (Fig. 7.1).
REMOVING THE PLATE / PARTITION
1. Place the disposer on one side and place it screw-
driver into the connection for the dishwasher, pushing
it until it will not rest against the partition in the end of
the branch pipe.
2. With several blows of the hammer, knock out the sep-
tum in the branch pipe (Fig. 7.1).
3. Remove the embossed partition from the disposer
bowl. If necessary to connect the dishwasher, then it
should be connected to the inlet of the overow out-
let pipes To connect to the overow inlet, remove the
exhaust pipe cover by unscrewing the cover (Fig. 7.3).
7. CONNECTING THE DISPOSER TO THE FIXING UNIT
ATTENTION!
To avoid injury, follow the so that during the removal
and installation of a part Your body was not under the
disposer; during the installation it is possible to drop it.
Remove any objects from the grinding chamber prod-
uct before installing it on the sink.
1. Install the product in such a way that provide easy
access to the restart button engine located in the lower
part of the body. Do not block this place with any ob-
jects.
2. Place the disposer with three mounting loops
(1) into the sliding position by mounting rails (2).
(Fig. 8.1)
3. Lift the disposer, insert the top end (installation gas-
ket) in the mounting and turn the setting ring to the right
(with a wrench or adjustable pliers) until the mounting
loops are xed (3) with respect to the mounting rails
(Fig. 8.2).
Make sure that all three mounting loops are locked. Dis-
poser is installed.
4. Run water into the sink, then check the connections
