for leaks.

5. Insert the noise absorbing screen into the drain hole

at side up. (Fig.8.3)

8. CONNECTING THE OUTLET PIPE

• To the DRAIN PIPE ATTENTION!

• It is recommended to wear protective goggles when

installing the disposer.

• For all models, the drain pipe is connected using a

screw connection (Fig. 9.2). First connect the hydrau-

lic lock to the disposer and then to the drain. For the

connection a siphon with smooth walls should be

used.

• Use a sanitary sealant only for connecting the ange

of the sink with the disposer.

• Do not use sealants for threaded pipe connections or

anaerobic screwed sealants. They can damage the

product.

• Regularly check the disposer and ttings for water

leaks, since leaks water can cause damage to prop-

erty.

• The manufacturer is not responsible for damage to

property as a result of water leaks.

INSTALLING THE DRAINAGE SYSTEM

1. Put the ange (2) on the drain pipe Insert the rubber

seal (1). Fasten drain tube, tightly pulling it to the body

disposer with screws (4). (Fig. 9.1)

9. CONNECTING THE DISPOSER TO THE ELECTRICAL

NETWORK

ATTENTION! ELECTRIC SHOCK CURRENT

To prevent electric shock, turn off the power before in-

stalling or servicing the product.

If you are not qualied enough, call an electrician to

connect the product to the power.

If a three–pin grounding–type plug is used to connect a

three–contact outlet with ground.

Do not modify the design of the plug supplied with the

device.

Improper equipment grounding may cause electric

shock current.

All electrical connections must comply with the electri-

cal and norms.

Do not connect the ground to the feed pipe gas.

Do not power on the distribution shield until you have

installed the sockets with proper grounding.

If the power cord is damaged, it must be replaced at the

service center.

NOTE: Access to a grounded outlet is required. In-

stalling all additional outlets must be carried out by a

qualied electrician, and all outlets must be properly

grounded.

Turn ON/OFF device

Depending on the models BORT disposer are equipped

with two types of control: a wireless (wall) switch or a

pneumatic switch.

Wireless (wall) switch

The disposer of the “Control and FullControl” series are

equipped with a wireless wall mount switch.

The switch should be located in a convenient (safe for

children) place above the table top.

For instal the switch to the wall, use double–sided tape.

For activate / deactivate the device, hold down the key

for 2–3 seconds.

Battery type: Voltage: 12V; Size: A27

Air switch

Disposer is equipped with an air switch and a connect-

ing pipe (except “Control” series).

INSTALLATION OF AIR SWITCH

1. Drill a hole with a diameter of 32 mm in suitable top

or top the panel of a sink. Some sinks may already have

a suitable A hole for the opening of which is necessary

remove the cover.

2. Unscrew the nut from the body of the push button,

while holding the stainless steel washer and rubber

gasket in place. Place one end of the PVC tube on the

spout on the body Press the other end to A hole in the

table top and a nut located under the countertop. (Fig.

10.2)

3. Place the push button housing in the hole and tighten

the nut underneath countertop (enough arm effort). Do

not use the key to tighten nut. (Fig. 10.3)

4. Take the other end of the duct and tightly put it on

the spout of the air switch located on the bottom of

the disposer. (Fig.10.4) Hand tighten the clamping nut.

The disposer installation is complete. Before using the

product, read all of the instructions. operation and safe-

ty contained in paragraph 10 of this manual. In conclu-

sion, install the plug in the sink in the Closed position.

Fill the sink with water, Remove the plug and check the

connections on the a water leakage.

10. ATTENTION! IMPORTANT INSTRUCTIONS FOR

SAFETY

• If the air switch does not work, remove the plug power
