8
Z11 Series
(7) 2.5” HDD / SSD Optional
2.5" HDD and SSDs can be installed on the right side of case as shown in the
diagram below.
Bolt B
Top Panel Fan (120/140 mm) Installation
When installing fan, press the Top Panel’s eight Hook’s towards each other
to remove and install as shown in diagram below. The Z11 comes with one
120mm Fan pre-installed.
(8) Optional Fan Installation and Replacement
※
Power and I / O ports to connect please refer to your motherboard. manual.
※
Product design and specications may be revised to improve quality and performance.
Front Panel I/O Port
MotherBoard
※
USB 3.0 is only supported in Z11 Plus /
Z11 PLUS HF1
HD Audio
Audio
USB 2.0 X 2
USB 3.0 USB 3.0or
Reset
HDD LED
AC ’97
