4-3. Do-it-yourself maintenance
4
Maintenance and care
TMC corolla_EE
24 ETCS*
1
10 A
Multiport fuel injection system/
sequential multiport fuel injection
system
25 AM2 30 A Starting system, IG2 NO. 2
26 STRG LOCK 20 A Steering lock system
27 IGT/INJ
*
1
15 A
Multiport fuel injection system/
sequential multiport fuel injection
system, starting system
28 EFI MAIN
20 A
*
1
Multiport fuel injection system/
sequential multiport fuel injection
system, EFI NO. 1, EFI NO. 2
30 A
*
2
29 HORN 10 A Horn
30 IG2 15 A
Multiport fuel injection system/
sequential multiport fuel injection
system, starting system, IG2 NO.
2, IGN, METER
31 HTR SUB NO. 1
30 A
*
5
Air conditioning system
50 A
*
6
32 HTR SUB NO. 2 30 A Air conditioning system
33 HTR SUB NO. 3 30 A Air conditioning system
34 FR DEICER
*
1
20 A No circuit
35 ABS NO. 2 30 A
Anti-lock brake system, vehicle sta-
bility control system
36 STV HTR
*
2
25 A Power heater
37 WIP-S 7.5 A
Charging system
38 IG2 NO. 2 7.5 A Starting system, AM2, AM2 NO. 2
39 EFI NO. 2 10 A
Multiport fuel injection system/
sequential multiport fuel injection
system
Fuse Ampere Circuit
