386
4-3. Do-it-yourself maintenance
TMC corolla_EE
7 EPS 60 A Electric power steering
8GLOW
*
2
80 A Engine glow system
9P-SYSTEM
*
1
30 A No circuit
10 P/I 50 A EFI MAIN, HORN, IG2
11 H-LP MAIN 50 A
H-LP LH LO, H-LP RH LO, H-LP
LH HI, H-LP RH HI
12 AMT
*
7
50 A Multi-mode manual transmission
13 SPARE 10 A Spare fuse
14 SPARE 30 A Spare fuse
15 SPARE 20 A Spare fuse
16 ECU-B3
*
2
7.5 A
Multiport fuel injection system/
sequential multiport fuel injection
system
17 ECU-B2 10 A
Multi-mode manual transmission,
air conditioning system, smart entry
& start system, power windows
18 ECU-B 10 A
Main body ECU, gauge and meters,
vehicle stability control system,
power door lock system, starting sys-
tem, charging system
19 RAD NO. 1 15 A Audio system
20 DOME 10 A
Interior lights, trunk light, vanity
lights, smart entry & start system,
wireless remote control, engine
switch light
21 AM2 NO. 2 7.5 A
Main body ECU
,
multiport fuel
injection system/sequential multi-
port fuel injection system, starting
system
22 ALT-S 7.5 A Charging system
23 TURN-HAZ 10 A Turn signal lights
Fuse Ampere Circuit
