390

4-3. Do-it-yourself maintenance

TMC corolla_EE

11 IGN 7.5 A

Steering lock system, SRS airbag

system, multi-mode manual trans-

mission, multiport fuel injection sys-

tem/sequential multiport fuel

injection system, smart entry &

start system, charging system,

starting system

12 METER 7.5 A Gauge and meters

13 SEAT HTR 15 A Seat heaters

14 HTR-IG 10 A

Air conditioning system, rear win-

dow defogger, power heater

15 WIPER 25 A Windshield wipers, rain sensor

16 WASHER 15 A Windshield washer

17 ECU-IG NO. 1 10 A

Automatic headlight leveling sys-

tem, main body ECU, electric

power steering, electric cooling fan,

shift lock control system, rain sen-

sor, anti-lock brake system, vehi-

cle stability control system,

headlight cleaner

18 ECU-IG NO. 2 10 A

Back-up lights, charging system,

auto anti-glare inside rear view mir-

ror, rear window defogger, air con-

ditioning system, emergency

flashers, front passenger’s seat

belt reminder light, rear view moni-

tor system, multiport fuel injection

system/sequential multiport fuel

injection system

19 OBD 7.5 A On-board diagnosis system

Fuse Ampere Circuit
