Specifications

CPU

∙ Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000

G-Series, 3000 Series, 3000 G-Series, 2000 Series, 2000

G-Series and 1000 Series Desktop Processor and Athlon™

with Radeon™ Vega Graphics desktop processors

∙ Supports Processor socket AM4

* Please go to www.msi.com to get the newest support status as new processors

are released.

Chipset AMD B450 Chipset

Memory

∙ 2x DDR4 memory slots, support up to 64GB*

∙ Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/

3066/ 3200 MHz by JEDEC

∙ Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466

/3600/ 3733 /3866 /4000 /4133+ MHz by A-XMP OC MODE

∙ Supports Dual-Channel mode

∙ Supports non-ECC, UDIMM memory

∙ Supports ECC UDIMM memory (non-ECC mode)

∙ Supports un-buffered memory

* Please refer to www.msi.com for more information on compatible memory.

Expansion Slots

∙ 1x PCIe x16 slot

• PCI_E1 slot (From CPU)

• AMD Ryzen™ 5000 Series, 5000 G-Series, 4000

G-Series, 3000 Series, 2000 Series, and 1000 Series

desktop processors support up to PCIe 3.0 x16

• AMD Ryzen™ 3000 G-Series and 2000 G-Series

desktop processors support up to PCIe 3.0 x8

• Athlon™ with Radeon™ Vega Graphics desktop

processors support up to PCIe 3.0 x4

∙ 1x PCIe x1 slot

• PCI_E2 slot (From B450 chipset)

• Supports PCIe 2.0 x1

Onboard Graphics

∙ 1x DVI-D port, supports a maximum resolution of

1920x1200 60Hz*/ **

∙ 1x HDMI™ 1.4 port, supports a maximum resolution of 4K

24Hz*/**

* Available only on processors featuring integrated graphics.

** Graphics specifications may vary depending on the CPU installed.

Continued on next column
