Continued from previous column

SATA Ports

∙ 4x SATA 6Gb/s ports

• SATA1~4 (From B450 chipset)

M.2 SSD Slots

∙ 1x M.2 slot (Key M)

• M2_1 slot (From CPU)

• Supports PCIe 3.0 x4 (AMD Ryzen™ 5000 Series, 5000

G-Series, 4000 G-Series, 3000 Series, 3000 G-Series,

2000 Series, 2000 G-Series, and 1000 Series desktop

processors)

• Supports PCIe 3.0 x2 (Athlon™ with Radeon™ Vega

Graphics)

• Supports SATA 6Gb/s

• Supports 2242/ 2260/ 2280 storage device

RAID

∙ Supports RAID 0, RAID 1 and RAID 10 for SATA storage

devices

Audio

Realtek® ALC897 Codec

∙ 7.1-Channel High Definition Audio

LAN ∙ 1x Realtek® 8125 2.5Gbps LAN controller

Power Connectors

∙ 1x 24-pin ATX main power connector

∙ 1x 4-pin +12V power connector

Internal USB

Connectors

∙ 1x USB 3.2 Gen 1 5Gbps connector (From B450 chipset)

• Supports additional 2 USB 3.2 Gen 1 5Gbps ports

∙ 2x USB 2.0 connectors (From B450 chipset)

• Supports additional 4 USB 2.0 ports

Fan Connectors

∙ 1x 4-pin CPU fan connector

∙ 1x 4-pin system fan connector

System Connectors

∙ 1x Front panel audio connector

∙ 2x System panel connectors

∙ 1x Chassis Intrusion connector

∙ 1x TPM module connector

∙ 1x Serial port connector

Jumpers ∙ 1x Clear CMOS jumper

Continued on next column
