that the voltage on the serial number data

plate on the bottom of the device

corresponds to that of the domestic

environment where it will be installed. ●

Do not use extension leads. ● The earth

power cable must be 2cm longer than the

other cables. ● If the electrical appliance

is not supplied with a power cable, use

one with a minimum conductor diameter of

2.5 mm2 for power up to 7200 Watt; for

higher power levels, the diameter must be

4 mm2. ● The temperature must not

reach 50°C above room temperature

anywhere along the cable. ● The

appliance is intended for permanent

connection to the power supply.

● Please note! Before reconnecting the

circuit to the mains power supply, make

sure that it is working correctly, always

check that the power cable is correctly

installed. ● Please note! The

interconnection cable must be replaced by

the authorised technical support service or

by a person with similar qualifications.

Assembly

Before starting the installation:

• After unpacking the product, check that it has not

been damaged during transport and in the event of

problem, please contact the reseller or the Customer

support service before installing it.

• Check that the product is the right size for the installation

area.

• Check for accessories (e.g. bags containing screws,

warranty certificates, etc.) inside the packaging (placed

there for transport reasons). Remove and keep them safe,

if present.

• Also check that there is a power socket near the

installation area.

Preparing the cabinet for installation:

- The product cannot be installed above cooling appliances,

dishwashers, heaters, ovens, washing machines and

dryers.

- Create the cut-outs in the cabinet before inserting the hob

and carefully remove any shavings or sawdust.

IMPORTANT: use a single-component adhesive sealant (S),

which withstands temperatures up to 250°; before

installation, thoroughly clean the surfaces to stick and

eliminate any substance that may compromise adhesion,

(e.g. release agents, preservatives, fats, oil, dust, traces of

old adhesives, etc.); the adhesive should be uniformly

spread all around the outside of the frame; after sticking,

leave the adhesive to dry for about 24 hours.

Caution! Failure to install screws and

fasteners in accordance with these

instructions may result in electrical

hazards.

Note: to ensure the correct installation of the product, it is

recommended to tape the pipes using an adhesive with the

following characteristics:

- soft elastic PVC film, with an acrylic-based adhesive

- compliant with DIN EN 60454 regulations

- flame retardant

- excellent resistance to wear

- resistant to temperature fluctuations

- can be used at low temperatures

Note : the product is equipped with a Power Limitator function,

which allows a maximum power limit to be set.

Size the electrical system protection according to the selected

Power Limitation level.

For further details see the “Use and Maintenance” manual.

The device can also be used in combination with a Window

sensor KIT (not supplied by the manufacturer).

If the Window sensor KIT is installed (only in the case of use in

EXTRACTOR mode), air extraction will halt every time the

window in the room, on which the KIT is applied, is closed.

• The KIT must be electrically connected to the device by

qualified and specialised technical personnel.

• The KIT must be certified separately in accordance with

the safety standards for the component and its use with

the device. Installation must be carried out in accordance

with current regulations for domestic systems.

PLEASE NOTE:

• the wiring of the KIT to be connected to the device must

be part of a certified safety extra-low voltage (SELV) circuit.

• the manufacturer of this device declines all liability for

any inconvenience, damage or fires caused by defects

and/or problems associated with the malfunction and/or

incorrect installation of the KIT.

DE - Warnungen und

Vorsichtsmaßnahmen

Die in diesem Handbuch aufgeführten Anleitungen müssen

streng eingehalten werden. Es wird für allfällige

Zwischenfälle, Schäden und Brände im Gerät nicht gehaftet, die

aus der Nichteinhaltung der in diesem Handbuch aufgeführten

Anleitungen stammen. Das Gerät ist ausschließlich für den

häuslichen Gebrauch zum Kochen von Lebensmitteln und zum

Absaugen von Dämpfen aus dem Kochvorgang selbst

bestimmt. Andere Verwendungen (wie z.B. die Raumheizung)

sind verboten. Der Hersteller lehnt jegliche Haftung für

Missbräuche oder fehlerhafte Einstellungen der Steuerelemente

ab.

Lesen Sie die Anleitung sorgfältig durch: Es gibt wichtige

Informationen zur Installation, zum Gebrauch und zur

Sicherheit.
