The specifications of any product may change without prior notice to improve performance.
2
Korean Patent Application No. 2005-117680
Korean Design Application No. 2005-37714
Patent Applications pending in over 10 nations around the world including the United States, Europe,
China, and Taiwan.
4. Patents
6. Components
1) Common Components
❶
One CNPS8000
❷
One Thermal Grease
❸
One FAN MATE 2 (Fan Speed Controller)
❹
One Cable for FAN MATE 2
❺
One Double-sided Tape
(for attaching FAN MATE 2)
❻
One User’s Manual
2) Components for Intel Pentium
D/Pentium 4 (Socket 775)
❼
Two Clips for Socket 775
❽
One Backplate for Socket 775
3) Components for AMD AMD64
(Socket 754/939/940)
❾
One Clip-A for AMD64
❿
One Clip-B for AMD64
❸❹❺❻
❼
❾
❽
❿
❷
❶
1) Keep and store the product away from the reach of children.
2) Check the components list and condition of the product before
installation. If there is any problem, contact the shop of purchase
to get a replacement or refund.
3) If excessive force is exerted on the fan, it may result in
malfunction or damage to the product and/or system.
4) Zalman Tech Co., Ltd. is not responsible for any damages
due to external causes, including but not limited to, improper
use, problems with electrical power, accident, neglect,
alteration, repair, improper installation, and improper testing.
5) CPU and motherboard are subject to damage if the product
is incorrectly installed. Familiarize yourself with the “Installation”
steps before installing the CNPS8000.
6) See the picture on the right for product dimensions to check
whether the product interferes with any motherboard
components.
6) Avoid inserting objects or fingers into the fan while it is in
operation.
5. Precautions
PSU
VGA Card Slot
Case chassis Cover
50mm 58mm
54mm 54mm
System Fan
62.5mm
ODD
