Z7 Plus / Z7

(7)

Additional Fan Installation and Replacement (optional)

1) Side Panel Fan Installation (80/92/120/140㎜ Fans Compatible)

Tip

▶ For USB 2.0, e-SATA (Z7 Plus) and audio cables, please refer to the

motherboard’s manual.

▶ In the event that the Power LED/HDD LED connector’s polarities(+/-) are

reversed, the LED will not function properly.

The Z7 Plus comes equipped with one 120㎜ Fan. For additional fan

installation, remove the Fan Cover(left) and install the fan(right) as shown

below.
