23 24

EN EN

Product

Name NAVEE Electric Scooter

Model NKT2208-A25

Dimensions

Vehicle: L × W × H

[1]

(mm) 1140 × 483 × 1189

After Folding: L × W × H (mm) 1140 × 483 × 490

Net Weight Vehicle Net Weight (kg) 16.2

Rider

Load Range (kg) 25–120

Age (years) 16–50

Body Length (cm) 120–200

Assembled

Electric Scooter

Max. Speed (km/h) 25

General Range

[2]

(km) Approx. 40

Max. Climbing Angle (%)

Approx. 15

Suitable Surfaces

Cement or asphalt road, with benches of less than 1 cm or crevices

narrower than 3 cm

Operating Temperature (°C) -10 to 40

Storage Temperature (°C) -20 to 45

IP Rating IP55

Charging Time(h) Approx. 4.5

Battery Pack

Model T2208-BA3A

Nominal Voltage (VDC) 36

Max. Charge Voltage (VDC) 42

Rated Energy (wh) 275.4

Intelligent Battery

Management System

Over-heating, short circuit, over-current, over-discharge, and

over-charge protection

Normal Charging Temperature

Range (°C)

0 to 40

Rated Capacity (Ah) 7.65 Ah

Wheel Motor Rated Power (kW; W) 0.3 ; 300

Battery Charger

Model

[3]

BCTA+71420-1701

Output Power(kW; W) 0.0697; 69.7

Input Voltage (VAC) 100–240

Max. Output Voltage(VDC) 42

Rated Output (VDC; A) 41; 1.7

Tire Front & Back Tires 10-inch pneumatic tires

Bluetooth

Frequency Band (GHz) 2.4000 – 2.4835 GHz

Max. RF Power (dBm) 8

[1] Vehicle height: From the ground to the top of the scooter.

[2] General range: Measured when there is no wind and at 77 ° F (25 ° C), the scooter is fully charged to ride at a constant speed of 9.3 mph

(15 km/h) on a flat surface with a load of 165.3 lbs (75 kg)

[3] To recharge the battery, only use the battery charger provided in the package. Please see battery charger parameters in Specifications.

11. Specifications

Item

Service

Object

Actions

Every

month

Every 3

months

Every 500 km/

6 months

Every 1000 km/

1 year

Every 10000 km/

3 years

Functions

Brake

Adjustment

Before adjusting, make sure

the scooter is turned o and

not being charged.

Tool: 4 mm hex key (the tool

needs to be prepared by the

user).

During adjusting, pull the end

of the brake cable to make the

cable tight.

Notes:

· If the brake is too tight, use

the tool to loosen the screw

by turning it counterclockwise,

pull the disc brake rocker arm

outwards, and then tighten the

screw. If the brake is too loose,

use the tool to loosen the screw

by turning it counterclockwise,

push the disc brake rocker arm

forwards, and then tighten the

screw.

√ √ √

Charging

Charge the scooter at a suitable

temperature. The indicator on

the battery charger is red when

the scooter is charging, and

turns green when the scooter

is fully charged. The control

panel will show the charging

status simultaneously during

charging.

√ √ √

Steering

Turn the handlebar 60° to the

left and right to make sure the

turning angle is correct and the

steering is free from resistance

and stagnation.

√ √

Important

Components

Battery

Assembly

Fully charge the scooter before

leaving it unused for a long

time, and turn it on to charge

every 60 days.

√
