12
16. Flange
17. Drain pipe with a knee
2. DISCONNECTION OF THE DROP HORN AT
TENTION!
At the time of installation of the device is
recommended Wear safety glasses. Loosen the nut
on the top of the water trap with a pipe wrench.
relative humidity not more than 80%. Loosen the
nut on the top of the extension pipe. Remove the
extension pipe.
Loosen the nut at the bottom of the washing
ange.
Push the washing ange upwards through drain
hole of the sink and remove it.
CLEAN THE WASH FAN WRAPPING PLACE FROM
THE SEALANT OR THE GARBAGE.
NOTE: It may be necessary to expand the drain
hole for installation ange fastening disposer.
Equipment for extending the drainage hole is
purchased separately.
3. DISASSEMBLY OF THE ASSEMBLY UNIT
• Turn over the assembly and loosen the three
xing screws (1) The access to the ring (2).
• Disconnect the retaining ring from the ange
with a screwdriver. Now the assembly unit can be
disassembled.
4. ATTACHING THE FIXING ASSEMBLY TO WASH-
ING Fig.5.1.
ATTENTION! To install the disposer, the thickness
of the sink in the area of the drain hole should be
no more than 18 mm.
1. Install one or two rubber gaskets (2) under the
washing ange (1). Make sure that The drainage
hole is not clogged, and set to ange washer /
gasket. In order to The ange of the sink became
in place, you need to crush it with a heavy load. (To
avoid scratches, use a towel as a lining.)
2. Put the second rubber part on the bottom of
the kitchen sink a gasket (2), a cardboard gasket
(optional) (3) and a metal support ring (4) (at side
up).
3. While holding the second rubber gasket,
cardboard padding (optional) and a metal support
ring, put the mounting ring (5) on the ange of the
sink so that it aligned with the support ring.
Production date:
Is indicated on the packaging of the goods.
Shelf life:
Shelf life is not limited (subject to storage conditions).
Storage conditions:
Products are stored in dry, ventilated warehouses at tem-
peratures from 0 ° C to +40 ° C with a relative humidity of
not more than 80%.
Transportation:
It is strongly prohibited dropping and any mechanical im-
pact on the packaging during transportation.
When unloading / loading, it is not allowed to use any
type of equipment that works on the principle of packing
clamping.
REQUIRED TOOLS AND MATERIALS:
Screwdriver, Hinged pliers, insulation tape, protec-
tive glasses.
REQUIRED INSTRUMENTS, MATERIALS AND
OPTIONAL EQUIPMENT:
a Phillips screwdriver, a drainage drill, electrical
terminal 9.5 mm, threaded nuts (2), siphon 38 mm,
drill 32 mm, hammer, hacksaw, water hose clamp,
pipe pliers, copper grounding wire, dishwasher
drainage pipe kit, electric switch, extension pipe.
1. DESCRIPTION OF THE PRODUCT FIG.1.1
Assembly unit
1. Stopper
2. Washing ange
3. Rubber gaskets (2)
4. Support ring
5. Mounting ring
6. Screws
7. Locking ring
8. Sound attenuating screen Disposer
9. Installation gasket / protective reector
10. Eyelets
11. Lower mounting ring
12. Drain the dishwasher
13. Outlet opening Drainage system
14. Mounting Screws
15. Rubber gasket
